24MB35PY
24MB35PY
  • READER MODE
  • FLICKER-SAFE
24MB35PY

BASIC

  • Screen Size
    23.8
    Panel Type
    IPS
  • Color Gamut
    72%
    Color Depth (Number of colors)
    16.7M
  • Pixel pitch (mm)
    0.275*0.275
    Aspect Ratio
    16:9
  • Resolution
    1920*1080
    Brightness (cd/m²)
    250 cd/m2 (Typ)
    200 cd/m2 (Min)
  • Contrast Ratio (DFC)
    5M:1
    Response Time (GTG)
    5ms (High)
  • Viewing Angle (CR≥10)
    178/178 (CR≥10)
    Surface Treatment
    Anti-Glare 3H

INPUTS/OUTPUTS

  • [Jack Location] - Signal Input
    Vertical
    D-Sub
    Yes
  • DVI-D
    Yes
    Display Port
    Yes (1.2)
  • Others
    USB 1Up/2Down
    [Jack Location] - Audio Input
    Vertical
  • PC Audio In
    Yes

SPEAKER

  • Type
    2ch stereo
    Audio output
    1W x 2

POWER

  • Power Type (Adapter or LIPS)
    Built-In Power (Power only)
    Input
    AC100~240V 50~60Hz
  • Power: Normal On (Typ.)
    24W
    Power Save/Sleep Mode(Max)
    0.3W
  • DC Off(Max)
    0.3W
    Output(for Speaker)
    27W(12V/2.3A)

FREQUENCY

  • H-Frequency (Analog)
    30~83kHz
    V-Frequency (Analog)
    56∼75kHz
  • H-Frequency (Digital)
    30~83kHz
    V-Frequency (Digital)
    56~75kHz

RESOLUTION

  • Analog (PC)
    1920*1080
    Digital (PC)
    1920*1080
  • DP (PC)
    1920*1080

CONTROL KEY

  • [Key Location]
    Front
    Key Number (Power Key Included)
    6 keys
  • Key Type
    Tact
    LED Color (On mode)
    White
  • LED Color (Power save mode)
    White (Blinking)

OSD

  • Country (Language)
    English, Germanic, French, Spanish, Italian, Swedish, Finnish, Portuguese, Polish, Russian, Greek, Chinese, Japanese, Korean, Ukrainian, Portuguese(brazil), Hindi
    Number of Language
    17

SPECIAL FEATURE

  • Original Ratio
    Yes
    DDC/CI
    Yes
  • HDCP
    Yes
    Intelligent Auto (Auto Resolution)
    Yes
  • Plug & Play
    Yes
    Reader Mode
    Yes
  • Flicker Safe
    Yes
    SUPER Energy Saving
    Yes
  • Six Axis Control
    Yes
    RTC
    Yes
  • Off Timer
    Yes
    Factory Calibration
    Yes

MECHANIC

  • Front Color
    Black Texture
    Back Cover Color
    Black Texture
  • Stand Color
    Black Texture
    Base Color
    Black Texture
  • Others
    Black Texture
    Base Detchable
    Yes
  • Tilt
    -5º (front) ~ 20º (rear)
    Swivel
    Yes
  • Pivot
    Yes (90º)
    Height(mm)
    120mm range

DIMENSION( W*D*H)(MM)

  • Set (with Stand)
    569*271*432
    Set (without Stand)
    569*63*342
  • Wall Mount
    VESA Compatible (100mmx100mm)

WEIGHT(KG)

  • Set (with Stand)
    5.1
    Set (without Stand)
    4.7

STANDARD

  • TCO
    6.0
    UL(cUL)
    Yes
  • FCC-B, CE
    Yes
    EPA 6.0
    Yes
  • EPEAT
    Gold
    ISO13406-2(ISO 9241-307)
    Yes
  • TUV-GS
    Yes
    TUV-Ergo
    Yes
  • Windows
    Yes (Win8)

ACCESSORIES

  • Power Cord
    Yes
    D-Sub
    Yes
  • DVI-D
    Yes
    USB
    Yes
  • DP
    Yes
    PC Audio
    Yes
