Key Features
Outdoor and indoor unit are connected by water pipes, preventing any refrigerant leakage and simplifying installation.
Wide operation range ensures remarkable heating performance even in an extremely cold weather.
Noise reduction technology provides quieter and more comfortable experience, increasing installation flexibility in urban areas.
Seasonal space heating efficiency (ηS) (35℃ / 55℃)
179 / 135
Seasonal space heating eff. class (35℃ / 55℃)
A+++/A++
SCOP (35℃ / 55℃)
4.55 / 3.45
Heating capacity (kW)
16.00
COP
4.80
Heating capacity (kW)
13.80
COP
3.60
Heating capacity (kW)
12.00
COP
2.80
Cooling capacity (kW)
16.00
EER
4.00
Cooling capacity (kW)
16.00
EER
2.50
Cooling (Min. ~ Max.) (℃)
5 ~ 48
Heating & DHW (Min. ~ Max.) (℃)
-25 ~ 35
Heating (Min. ~ Max.) (℃)
15 ~ 65
Cooling (Min. ~ Max.) (℃)
5 ~ 27
DHW (Min. ~ Max.) (℃)
15 ~ 80
Type
R32
GWP
675
Precharged amount (g)
2,100
Inlet diameter (inch)
Male PT 1"
Outlet diameter (inch)
Male PT 1"
Inlet/outlet diameter for ODU connection (inch)
Male PT 1"
Inlet/outlet diameter for space heating (inch)
Male PT 1"
Rated / low noise mode (dB(A))
63 / 60
Rated (dB(A))
44
Rated / low noise mode (dB(A))
41 / 38
Rated (dB(A))
36
Outdoor unit (W × H × D) (mm)
950 × 1,380 × 330
Indoor unit (W × H × D) (mm)
490 × 850 × 315
Outdoor unit (Empty) (kg)
91.7
Indoor unit (Empty) (kg)
30.5
Outdoor unit (Color / RAL code)
Warm gray / RAL 7044
Indoor unit (Color / RAL code)
Noble white / RAL 9016
Voltage, phase, frequency (V, Ø, Hz)
380-415, 3, 50
