75XF3C
OPEN-FRAME 75XF3C SERIES
  • Open-frame
  • Brightness: 3,000 cd/m²
  • Provides full brightness for 30,000 hours
  • Life time: 50,000 hours
  • Operating Temperature: 0°C to 50°C
  • For outdoor use, enclosure required

component-OBScountrySelectDesc

OPEN-FRAME 75XF3C SERIES

High Operating Temperature

Even under high operating temperature up to 50°C, it presents clearer images without hot spots.
High Operating Temperature High Operating Temperature

Conformal Coating

The XF3C signage has been designed with the LG Conformal Coating to provide additional protection to circuit boards in harsh environments such as dust and humidity.
Conformal Coating Conformal Coating

Increased Brightness

The high brightness outdoor display maintains high picture quality and image readability in an outdoor environment even when used for continuous business use (24/7).
Increased Brightness Increased Brightness

Lifelike Picture Quality

LG IPS panels allow you to enjoy lifelike picture quality with minimal variation from wider viewing angles. Featuring excellent consistency in colour temperature and less change in contrast, LG IPS panels boast excellent image reproduction.
Lifelike Picture Quality Lifelike Picture Quality

Reduced Blackening Effect

Even under direct sunlight exposure, LG commercial monitors experience reduced blackening defects under 110°C and provide superior image quality for outdoor usage.
No Blackening Effect No Blackening Effect

Smart Brightness Control

The high brightness outdoor display maintains high picture quality and image readability in an outdoor environment.
Smart Brightness Control Smart Brightness Control

Real-Time Remote Monitoring

Real Time Display Remote Management through SuperSign C or Simple Network Management Protocols (SNMP) is available in addition to RS-232C and other network protocol.
Real-Time Remote Monitoring Real-Time Remote Monitoring

Saving System Log Files

The XF3C supports 'log file back-up' of display failure and allows to check when specific error occured.
Saving System Log Files Saving System Log Files

PANEL

  • Screen Size
    75" (189cm)
    Panel Technology
    IPS, M+ (WRGB)
  • Aspect Ratio
    16 : 9
    Resolution
    3,840 x 2,160 (UHD)
  • Brightness
    3,000 cd/m2 (Typ)
    Contrast Ratio
    1,200:1
  • Viewing Angle (H x V)
    178 x 178
    Colour Depth
    10bit (Dethering)
  • Surface Treatment
    AGLR(Haze 3%) ,QWP
    Life time
    50,000 Hrs
  • Operation Hours
    24 Hrs
    Orientation
    Landscape & Portrait

CONNECTIVITY

  • Input
    HDMI (2), DP, DVI-D, Audio, USB, SD Card
    Output
    DP, External Speaker
  • External Control
    RS232C In/out, RJ45 In, IR Receiver In

PHYSICAL SPECIFICATION

  • Bezel Colour
    Black
    Bezel Width
    11.8 mm (Even)
  • Monitor Dimension (W x H x D)
    1,675.2 x 953.6 x 123.9 mm
    Weight (Head)
    36.7 kg
  • Carton Dimensions (W x H x D)
    1,816 x 1,106 x 285 mm
    Packed Weight
    46.3 kg

SPECIAL FEATURES

  • SPECIAL FEATURES
    WebOS 3.0, Temperature Sensor, Cooling Fan, Auto Brightness Sensor, Energy Saving, Smart Energy Saving, Tile Mode (up to 15 x 15), Natural Mode@Tile Mode, Source Selection, Brightness/Contrast/Backlight, DPM Select, File Play with USB, Internal Memory (8GB, System 4GB + Available 4GB), Wi-Fi Dongle Ready

ENVIRONMENT CONDITIONS

  • Operation Temperature1
    0 °C to 50 °C (w/o Direct Sunlight) ; 0 °C to 40 °C (Direct Sunlight)
    1) Without direct sunlight or with cooling systems in direct sunlight
    Operation Humidity
    10% to 85%

POWER

  • Power Supply
    Built-In Power
    Power Type
    100-240V~, 50/60Hz
  • Power Consumption (Typ. / Max.)
    660 W / 695 W
    Power Consumption (Smart Energy Saving)
    320 W

SOUND

  • Speaker
    20 W (10 W x 2) for External Speaker

STANDARD(CERTIFICATION)

  • Safety
    AS/NZS 60950,CB Scheme
    EMC
    AS/NZS CISPR32,RCM(Class A)

SOFTWARE COMPATIBILITY

  • Content Management Software
    SuperSign CMS
    Control and Monitoring Software2
    SuperSign Control/Control+
    2) Software compatibility may change over time. Please contact LG sales representative for details.

ACCESSORIES

  • Basic
    Remote Controller (2 Batteries Included), Power Cord, IR Extension Kit, HDMI Cable, Manual (ESG&EIG)
    Optional
    Wi-Fi Dongle (AN-WF500)
    * Stand is not available
