LED Video Wall
Pixel Configuration
Single SMD
Pixel Pitch(mm)
1.875
Module Resolution (WxH)
160x120
Module Dimensions(WxH,mm)
300x225
Weight per Module (kg)
0.59
No. of Modules per Cabinet (WxH)
4x3
Cabinet Resolution (WxH)
640x360
Cabinet Dimensions (W x H x D, mm)
1,200x675x51
Cabinet Surface Area (m²)
0.810
Weight per Cabinet (kg/unit)
23.2
Weight per Square Meter (kg/m²)
28.6
Physical Pixel Density (pixels/m²)
284,444
Flatness of Cabinet (mm)
±0.5
Cabinet Material
Die-cast Aluminum
Service Access
Front
Max Brightness (After Calibration, nit)
600 / Peak 1,000
Color Temperature (K)
3,200~9,300
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
160
Brightness Uniformity
95%
Color Uniformity
±0.015Cx,Cy
Contrast Ratio
5,000:1 / Peak 9,000:1
Processing Depth (bit)
20 (HDR10, HDR10 Pro)
Power Consumption (W/Cabinet, Max.)
320
Power Consumption (W/Cabinet, Avg.)
210
Power Consumption (W/m², Max.)
395
Heat Dissipation (BTU/h/Cabinet, Max.)
1,091
Heat Dissipation (BTU/h/Cabinet, Avg.)
716
Heat Dissipation (BTU/h/m², Max.)
1347
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
3840
LED Lifetime (Half brightness)
100,000
Operating Temperature(℃)
0°C to +40°C
Operating Humidity
10-80%RH
IP Rating Front / Rear
IP20
Controller
CSAC-018K
To access more technical documentation and resources, please visit the LG B2B partner portal.
