Screen Size
86
Panel Technology
IPS
Back Light Type
Edge
Aspect Ratio
16:9
Native Resolution
3840 x 2160 (UHD)
Refresh Rate
120Hz
Brightness
500nit (Typ.)
Contrast Ratio
1,100:1
Dynamic CR
1,000,000:1
Colour gamut
NTSC 72%
Viewing Angle(H x V)
178 X 178
Colour Depth
10bib, 1.07Billion colours
Response Time
8ms (G to G)
Surface Treatment(Haze)
28%
Life time
50,000Hrs (Typ.)
Operation Hours (Hours/Day)
24/7
Portrait / Landscape
Yes / Yes
Transparency
N/A
QWP (Quarter Wave Plate)
N/A
HDMI IN
YES (3ea)
HDMI In (HDCP Ver.)
2.2/1.4
DP IN
YES (HDCP 2.2/1.3)
DVI-D In
YES (HDCP 1.4)
RGB In
NO
Audio In
YES
RS232C IN
YES
RJ45(LAN) IN
YES (1ea)
IR IN
YES
USB IN
USB2.0 Type A (1ea)
HDMI Out
YES
DP Out
NO
Audio Out
YES
Touch USB
NO
External Speaker Out
NO
RS232C Out
YES
RJ45(LAN) Out
NO
IR Out
NO
Daisy Chain
Input : HDMI, DP / Output : HDMI
Input
HDMI (3, HDMI1/HDMI2 : HDCP 2.2/1.4, HDMI3 : HDCP 1.4), DP (1, HDCP2.2/1.3), DVI-D (HDCP1.4), Audio In, RS232C IN (1, 4pin Phone-jack), RJ45(LAN), IR IN, USB2.0 Type A(1)
Output
HDMI Out, Audio Out, RS232C OUT (1, 4pin Phone-jack)
Bezel Colour
Black
Bezel Width
Even bezel : 14.3mm
Weight(Head)
49.0Kg
Packed Weight
72.5Kg (With Pallet)
Monitor Dimension(W x H x D)
1926.2 x 1097.2 x 60.6mm
(without Handle and LG Logo)
Monitor Dimension with Stand (W x H x D)
N/A
Handle
Yes
VESA™ Standard Mount Interface
600 x 400
Carton Dimensions (W x H x D)
2073 x 1250 x 285mm
Weight(Head+Stand)
N/A
Carton Dimensions(W x H x D) (Box outer size)
2073 x 1250 x 285mm
Internal Memory (eMMC)
16GB
Wi-Fi/BT (Built-in)
YES
Temperature Sensor
YES
Auto Brightness Sensor
YES
Pixel Sensor
NO
Proximity Sensor
NO
Current Sensor
NO
BLU Sensor
NO
Humidity Sensor
NO
Acceleration(Gyro) Sensor
YES
Power Indicator
NO
Local Key Operation
YES
FAN (Built-in)
NO
OS Ver. (webOS)
webOS 6.0
Local Contents Scheduling
YES
Group Manager
YES
USB Plug & Play
YES
Fail over
YES
Booting Logo Image
YES
No Signal Image
YES
RS232C Sync
YES
Local Network Sync
YES
Backlight Sync
NO
PIP
YES
PBP
YES (4PBP)
Screen Share
YES
Video Tag
YES (4 Video Tag)
Play via URL
YES
Screen Rotation
YES
External Input Rotation
YES
Gapless Playback
YES
Tile Mode Setting
YES
Setting Data Cloning
YES
SNMP
YES
ISM Method
YES
Auto Set ID
YES
Status Mailing
YES
Control Manager
YES
Cisco Certification
NO
Crestron Connected
YES
Smart Energy Saving
YES
PM mode
YES
Wake on LAN
YES
Network Ready
NO
Beacon
YES
HDMI-CEC
YES
SI Server Setting
YES
webRTC
YES
Pro:Idiom
YES
Brightness Compensation
NO
W/B Setting by Grey scale
NO
Scan Inversion
NO
Operation Temperature
0 °C to 40 °C
Operation Humidity
10 % to 80 %
Power Supply
AC 100-240V~, 50/60Hz
Power Type
Built-in Power
Typ.
215W (TBD)
Max.
280W (TBD)
BTU (British Thermal Unit)
733.69 BTU/Hr(Typ.), 955.5 BTU/Hr(Max) (TBD)
DPM
0.5W
Power off
0.5W
Smart Enegy Saving(~70%)
150.5W (TBD)
Speaker (Built-in)
YES (10W x 2)
Speaker
2073 x 1250 x 285mm
Safety
CB / NRTL
EMC
FCC Class "A" / CE / KC
ErP / Energy Star
Yes (NewErP) / No (TBD)
ePEAT(US only)
NO
OPS Type Compatible
Yes
OPS Power Built-in
NO
SuperSign CMS
Yes
SuperSign Control+
YES
SuperSign WB
Yes
SuperSign Cloud
NO
Promota
YES (Not available for EU/CIS)
Mobile CMS
Yes
Connected Care
YES
SuperSign Control / Control+
Yes / Yes
SuperSign Media Editor
Yes
Signage 365 Care
Yes
OSD
English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Turkish, Arabic
Basic
Remote Controller(include battery 2ea), Power Cord, QSG, Regulation Book, Phone to RS232C Gender
Optional
OPS Kit(KT-OPSF), LSW640A/B(Wall Mount)
Overlay Touch Compatibility
N/A
Smart Calibration
N/A
Tilt (Face up)
N/A
Tilt (Face down)
N/A
IP Rating
N/A
Conformal Coating (Power Board)
YES
Power Protection
N/A
Direct Sunlight
N/A
KEY FEATURE
Internal Memory 16 GB, Built-in Wi-Fi, Temperature Sensor, Auto Brightness sensor, Acceleration(Gyro) Sensor, Local Key Operation, webOS6.0, Embedded CMS (Local Contents Scheduling, Group Manager), USB Plug & Play, Fail over, Background Image (Booting Logo Image, No Signal Image), Sync Mode (RS-232C Sync, Local Network Sync), Multi-screen (PIP, PBP (4)), Screen Share, Video Tag (4), Play via URL, Rotation (Screen Rotation, External Input Rotation), Gapless Playback, Tile Mode Setting (Max. 15 × 15), Setting Data Cloning, SNMP, ISM Method, Auto Set ID, Status Mailing, Control Manager, 3rd Party Compatibility (Crestron Connected), Power (Smart Energy Saving, PM mode, Wake on LAN,Beacon, HDMI-CEC, SI Server Setting, webRTC, Pro:Idiom
