US665H Series
US665H Series
LG Smart Hotel TV with Effective Content Management
TV screens set up in the hotel provide hotel services and various information for users.
* 65 inch
* All images are for illustrative purposes only.
Pro:Centric Direct
A man is managing some contents and settings of TV in the hotel using Pro:Centric Direct solution through server.
* Some devices may have limited compatibility with the IoT and Voice Control function. Please contact the LG sales team to verify the compatibility before ordering.
* Magic Motion Remote is required (sold separately)
* Soft AP should be setup in the installation menu after the TV is turned on.
* Smart Mirroring may not be operated at the same time.
* This feature may have a restriction depending on the installation environment.
* Additional speaker is not included with this product.
Gallery
All Spec
INFO
-
Category
Pro:Centric Smart
DESIGN
-
Tool Name
UM73
-
Stand Type
1 Pole (Swivel)
-
Front Colour
Ceramic Black
VIDEO
-
HDR_HDR 10 Pro
YES
-
HDR_HLG (Hybrid Log Gamma)
YES
AUDIO (SOUND)
-
AI Sound
YES
-
Speaker (Audio Output)
20W
-
AI Acoustic Tuning
YES (Ready, MMR Required)
-
LG Sound Sync
YES
DISPLAY
-
Size (Inch)
43
-
Resolution
4K Ultra HD (3,840 x 2,160)
-
Brightness (Typ.)
300 nit
BROADCASTING SYSTEM
-
Digital
DVB-T2/C/S2
-
Analog (NTSC / SECAM / PAL)
SECAM / PAL
-
Teletext (Auto Teletext)
YES
HOSPITALITY SOLUTION
-
Pro:Centric Smart
YES
-
webRTC (Real Time Communication)
YES
-
Pro:Centric Direct
YES
-
Pro:Centric V
YES
-
Pro:Centric Server
YES
-
Quick Menu (Customizable Portal)
YES
-
Pro:Idiom (DRM)
YES
-
Pro:Idiom Media (DRM)
YES
-
Other DRM
SECUREMEDIA
SMART FUNCTION
-
webOS version
webOS 5.0
-
Web Browser
YES
-
Magic Remote Compatibility
YES (Ready)
-
Mood Display
YES
-
Gallery Mode
YES
-
Wi-Fi
YES
-
Bluetooth
YES
-
Soft AP
YES
-
Screen Share
YES
-
DIAL
YES
-
Bluetooth Audio Playback
YES
-
Voice Recognition (Standalone/Solution)
YES
-
IoT
YES
HOSPITALITY FEATURE
-
EzManager
YES
-
USB Cloning
YES
-
Wake on RF
YES
-
WOL
YES
-
SNMP
YES
-
Diagnostics
YES (IP Remote)
-
HTNG-CEC (Version)
YES (1.4)
-
Simplink(HDMI-CEC) (Version)
YES (1.4)
-
IR Out
YES (RS-232C, HDMI)
-
Multi IR Code
YES
-
Hotel Mode / PDM / Installer Menu
YES
-
Welcome Video
YES
-
Welcome Screen (Splash Image)
YES
-
Insert Image
YES
-
One Channel Map
YES
-
External Speaker Out / Line Out
YES (Ext. Speaker Out)
-
Instant ON
YES
-
V-Lan Tag
YES
-
Port Block
YES
-
Lock mode
YES (Limited)
-
RJP (Remote Jack Pack) Compatibility
YES
-
External Power Out
YES
-
Conformal Coating
YES
-
Energy Saving mode
YES
VERTICAL FUNCTION (HOSPITAL)
-
Healthcare Headphone Mode
YES
VERTICAL FUNCTION (CORPORATE/RETAIL)
-
RTC (Real Time Clock)
YES
-
NTP sync timer
YES
-
BEACON
YES
-
Video Tag
YES (2 Video)
MECHANICAL
-
VESA Compatible
200 x 200 mm
-
Kensington Lock
YES
DIMENSIONS/WEIGHT
-
Dimension with Stand (W x H x D)
973 x 626 x 303 mm
-
Dimension in Shipping (W x H x D)
1147 x 660 x 190 mm
-
Dimension without Stand (W x H x D)
973 x 572 x 85.0 mm
-
Bezel Width (L/R/U/B, On Bezel)
15.5/15.5/15.5/21.7 mm
-
Weight in Shipping
10.2 kg
-
Bezel Width (L/R/U/B, Off Bezel)
14.0/14.0/14.0/20.2 mm
-
Weight with Stand
8.1 kg
-
Weight without Stand
8.0 kg
POWER SPEC.
-
Power Supply (Voltage, Hz)
AC 100~240V 50/60Hz
-
Power Consumption(Max)
114W
-
Power Consumption(Typ)
97W
-
Standby Power Consumption
Under 0.5W
STANDARD
-
Safety
CB
-
EMC
CE
ACCESSORIES
-
Remote type
S-Con / MMR (Option)
-
Power Cable
YES (1.5M / Angle Type)
CONNECTIVITIES
-
HDMI In
YES (3ea)
-
USB (Ver.)
YES (2ea / 2.0)
-
RF In
YES (2ea)
-
Digital Audio Out (Optical)
YES
-
External Speaker Out(3.5mm Phone jack)
YES
-
Headphone Out
YES
-
CI Slot
YES (CI+ 1.4)
-
RJ45 (Usage Purpose)
2 (Ethernet, Aux)
-
RS-232C (D-Sub 9pin / Phone jack)
YES (D-Sub 9pin)
