All Spec
PANEL
-
Screen Size
22” (55 cm)
-
Panel Technology
IPS
-
Aspect Ratio
16:9
-
Native Resolution
1,920 x 1,080 (FHD)
-
Brightness
250 cd/m2
-
Contrast Ratio
1,000:1
-
Viewing Angle (H x V)
178° x 178°
-
Guaranteed Operating Hour
16 hrs / 7 days
CONNECTIVITY
-
Input
HDMI, RGB, Audio, USB 3.0
-
External Control
RS232C In, IR Receiver, Pixel Sensor, RJ45
PHYSICAL SPECIFICATION
-
Bezel Width
16.3 mm
-
Monitor Dimension(W x H x D)
510.3 x 302.1 x 53.8 mm
-
Weight (head)
3.6 kg
-
Carton Dimensions (W x H x D)
565 x 357 x 103 mm
-
Packed Weight
4.7 kg
-
VESA™ Standard Mount Interface
100 mm x 100 mm
ENVIRONMENT CONDITIONS
-
Operation Temperature
0°C to 40°C
-
Operation Humidity
10% to 80%
POWER
-
Power Supply
100-240V~, 50/60Hz
-
Power Consumption (Typical)
35W
-
Power Consumption (Smart Energy Saving)
On 25.13W / Off 29.76W
STANDARD(CERTIFICATION)
-
Safety
AS/NZS 60950, CB Scheme
-
EMC
AS/NZS CISPR32, RCM (Class A)
MEDIA PLAYER COMPATIBILITY
-
OPS Type Compatible
No
-
External Media Player Attachable
No
SOFTWARE COMPATIBILITY
-
SuperSign Lite/W
Yes
-
SuperSign C
Yes
ACCESSORIES
-
Basic
Remote Controller (include 2ea batteries), Power Cord, QSG, RGB Cable, Phone to RS232C Gender
-
Optional
Pixel Sensor (KT-SP0)
White Paper
To access more technical documentation and resources, please visit the LG B2B partner portal.
