22" 250 nits FHD Standard Signage
All Spec
ACCESSORIES
Basic
Remote Controller (include 2ea batteries), Power Cord, QSG, RGB Cable, Phone to RS232C Gender
Optional
Pixel Sensor (KT-SP0)
CONNECTIVITY
Input
HDMI, RGB, Audio, USB 3.0
External Control
RS232C In, IR Receiver, Pixel Sensor, RJ45
ENVIRONMENT CONDITIONS
Operation Temperature
0°C to 40°C
Operation Humidity
10% to 80%
MEDIA PLAYER COMPATIBILITY
OPS Type Compatible
No
External Media Player Attachable
No
PANEL
Screen Size
22” (55 cm)
Panel Technology
IPS
Aspect Ratio
16:9
Native Resolution
1,920 x 1,080 (FHD)
Brightness
250 cd/m<sup>2</sup>
Contrast Ratio
1,000:1
Viewing Angle (H x V)
178° x 178°
Guaranteed Operating Hour
16 hrs / 7 days
PHYSICAL SPECIFICATION
Bezel Width
16.3 mm
Monitor Dimension(W x H x D)
510.3 x 302.1 x 53.8 mm
Weight (head)
3.6 kg
Carton Dimensions (W x H x D)
565 x 357 x 103 mm
Packed Weight
4.7 kg
VESA™ Standard Mount Interface
100 mm x 100 mm
POWER
Power Supply
100-240V~, 50/60Hz
Power Consumption (Typical)
35W
Power Consumption (Smart Energy Saving)
On 25.13W / Off 29.76W
SOFTWARE COMPATIBILITY
SuperSign Lite/W
Yes
SuperSign C
Yes
STANDARD(CERTIFICATION)
Safety
AS/NZS 60950, CB Scheme
EMC
AS/NZS CISPR32, RCM (Class A)
White Paper
To access more technical documentation and resources, please visit the LG B2B partner portal.
