Full HD Signage
All Spec
PANEL
Screen Size
55" (139 cm)
Panel Technology
IPS
Aspect Ratio
16:9
Native Resolution
1920 x 1080(FHD)
Brightness
2500cd/m2
Contrast Ratio
1000:1
Dynamic CR
500,000:1
Viewing Angle (HxV)
178° x 178°
Surface Treatment
Hard coating(2H), Anti-reflection treatment (Reflectance 1.5%)
Life Time
50,000 Hours
Orientation
Portrait and Landscape
CONNECTIVITY
Input
HDMI(2), DP, DVI-D, Audio, USB, IR Receiver, Pixel Sensor
Output
DP, External Speaker Out (L/R)
External Control
RS232C (In/Out), RJ45
PHYSICAL SPECIFICATION
Bezel Width
9.9mm(L/R),12mm(T/B)
Monitor Dimension(W x H x D cm)
1235mm x 709mm x 106mm
Weight (head)
27kg
Carton Dimensions(W × H × D)
1336mm x 241mm x 810mm
Packed Weight
32kg
VESA™ Standard Mount Interface
600mm × 400mm
SPECIAL FEATURES
Additional
Temperature Sensor, Auto Brightness Sensor, Cooling FAN, Tile Mode, Brightness/Contrast/Backlight, Input Label, Sync Mode, Auto Power/Source Memory, Key Lock, Internal Memory(4GB)
ENVIRONMENT CONDITIONS
Operation Temperature
0°C to 50°C (w/o Direct Sunlight) 0°C to 40°C (Direct Sunlight)
Operation Humidity
10% to 80%
POWER
Power Supply
100-240V~, 50/60Hz
Power Type
Built-in Power
Power Consumption (Typ. / Max)
230W / 310W
Power Consumption (Smart Energy Saving)
100 W
STANDARD(CERTIFICATION)
Safety
AS / NZS 60950, CB Scheme
EMC
AS / NZS CISPR22, RCM (Class A)
Energy Rating
209kWh/year, 7 stars
SOFTWARE COMPATIBILITY
SuperSign-w lite / SuperSign-c
Yes / Yes
ACCESSORY
Accessory
Remote Controller (including battery 2ea), Power Cord, IR extension cable/PCB, HDMI Cable, Manual
Optional
N/A
White Paper
To access more technical documentation and resources, please visit the LG B2B partner portal.
