All Spec
PANEL
-
Screen Size
88” (223cm)
-
Panel Technology
IPS
-
Aspect Ratio
32:9
-
Native Resolution
3,850 x 1,080 (FHD)
-
Brightness
700 cd/m2 (Typ)
-
Contrast Ratio
1,100:1 (Typ)
-
Viewing Angle (H x V)
178 ° x 178 °
-
Guaranteed Operating Hour
24 hrs / 7 days
CONNECTIVITY
-
Input
HDMI(3), DP, OPS, DVI-D,USB 2.0, USB 3.0, SD Card
-
Output
DP, Anologue Audio (Line out), LAN Out
-
External Control
RS232C, RJ45, IR+B Receiver,Pixel Sensor
PHYSICAL SPECIFICATION
-
Bezel Width
4.4 mm (L/R), 5.9 mm (U/D)
-
Monitor Dimension(W x H x D)
2,158.3 x 611.2 x 103.9 mm
-
Weight (head)
38 kg
-
Carton Dimensions(W × H × D)
2,274 x 717 x 212 mm
-
Packed Weight
51 kg
-
VESA™ Standard Mount Interface
600 x 400 mm
ENVIRONMENT CONDITION
-
Operation Temperature
0˚C to 40˚C
-
Operation Humidity
10 % to 80 %
POWER
-
Power Supply
100-240V~, 50/60Hz
-
Power Consumption (Typical)
400W
-
Power Consumption (Smart Energy Saving)
120W
STANDARD(CERTIFICATION)
-
Safety
AS/NZS 60950, CB Scheme
-
EMC
AS/NZS CISPR32, RCM (Class A)
MEDIA PLAYER COMPATIBILITY
-
OPS Type Compatible
Yes
-
External Media Player Attatchable
No
SOFTWARE COMPATIBILITY
-
SuperSign Premium
Yes
-
SuperSign C
Yes
ACCESSORIES
-
Basic
Remote Controller (including battery 2 ea), Power Cord, DP (2.6 M), RS- 232C Cable (3 M), Owner's Manual (Website upload)
-
Optional
AN-WF500 (Wi-Fi USB Dongle), MP700, KT-OPSA (OPS KIT), KT-SP0 (RGB Sensor)
