All Spec
PANEL
-
Screen Size
75” (189 cm)
-
Panel Technology
IPS
-
Aspect Ratio
16:9
-
Native Resolution
3840 x 2160 (UHD)
-
Brightness
350 cd/m²
-
Contrast Ratio
1,200:1
-
Viewing Angle (H x V)
178 ° x 178 °
-
Guaranteed Operating Hour
24 hrs / 7 days
CONNECTIVITY
-
Input
HDMI, DP, DVI-D, Audio,USB 3.0, SD Card
-
Output
DP, Audio
-
External Control
RS232C, RJ45, IR Receiver,Pixel Sensor
PHYSICAL SPECIFICATION
-
Bezel Width
14.9 mm
-
Monitor Dimension(W x H x D)
1,682.4 x 960.3 x 57.9 mm
-
Weight (Head)
41.5 kg
-
Carton Dimensions(W × H × D)
1,816 x 1,123 x 228 mm
-
Packed Weight
49 kg
-
VESA™ Standard Mount Interface
600 x 400 mm
ENVIRONMENT CONDITION
-
Operation Temperature
0˚C to 40˚C
-
Operation Humidity
10 % to 80 %
POWER
-
Power Supply
100-240V~, 50/60Hz
-
Power Consumption (Typical)
160W
-
Power Consumption (Smart Energy Saving)
115W
STANDARD(CERTIFICATION)
-
Safety
AS/NZS 60950, CB Scheme
-
EMC
AS/NZS CISPR32, RCM (Class A)
MEDIA PLAYER COMPATIBILITY
-
OPS Type Compatible
Yes
-
External Media Player Attatchable
Yes (MP500/MP700)
SOFTWARE COMPATIBILITY
-
SuperSign Lite/W
Yes
-
SuperSign C
Yes
ACCESSORY
-
Basic
Remote Controller (include battery 2 ea), Power Cord, QSG, DP Cable , Regulation Book, Phone to RS232C Gender, Memory Cover
-
Optional
Pixel sensor (KT-SP0),Media player, OPS Kit (KT-OPSA),HD Base T (EB-B100) LSW640A/B (Wall Mount)-Speaker (SP-5200), Pixel sensor(KT-SP0), Media player, Wall bracket(LSW350B), VESA Adapter (AMB330S),OPS Kit (KT-OPSA),HD Base T (EB-B100)
