All Spec
PANEL
-
Screen Size
65" (164cm)
-
Panel Technology
OLED
-
Aspect Ratio
16 : 9
-
Native Resolution
3,840 x 2,160
-
Brightness
140/450 cd/m2 (APL* 100% / 25%) * Average Picture Level
-
Colour Gamut
129% sRGB
-
Viewing Angle (H x V)
120° x 120°
-
Response Time
1ms (G to G) (Typ.), 8 ms (MPRT)
-
Surface Treatment
Hard coating (2H), Anti-reflection
-
Life Time (Min.)
30,000 hrs
-
Orientation
Portrait
CONNECTIVITY
-
Input
HDMI (HDCP 2.2, External)
-
Output
-
-
External Control
RS232C IN, RJ45, IR Receiver
PHYSICAL SPECIFICATION
-
Bezel Colour
Black
-
Bezel Width
15, 26, 13.2, 13.2 mm (U, B, L, R Off-bezel)
-
Dimension (W x H x D)
(1 x 4 Model) Display: 3,123 x 2,120 x 8.5 mm (Module), 99 mm (Stand Neck)
-
Weight
(1 x 4 Model) 380 kg
-
Carton Dimensions (W x H x D)
1,038 x 858 x 1,281 mm (65EE5PC, include Pallet)
2,278 x 1,262 x 1,037 mm (65CVR4C, include Pallet)
SPECIAL FEATURES
-
Additional
Temperature Sensor, Cooling FAN, Tile Mode, Source Selection (HDMI, DP), DPM Select, Energy Saving, Internal Memory 128 GB (System 4 GB + Available 124 GB) Firmware update (LAN), HDMI-CEC, Fail over (DP, HDMI, Internal Memory) , DP daisy chain
ENVIRONMENT CONDITIONS
-
Operation Temperature
0 °C to 40 °C
-
Operation Humidity
10% to 80%
POWER
-
Power Supply
100-240V~, 50/60Hz
-
Power Type
Built-In Power
POWER CONSUMPTION
-
Typ.
230 W
-
DPM
3 W
-
Power Off
0.5 W
STANDARD(CERTIFICATION)
-
Safety
AS/NZS 60950, CB Scheme
-
EMC
AS/NZS CISPR 22, RCM (Class A)
-
Energy Rating
N/A
MEDIA PLAYER COMPATIBILITY
-
OPS Type Compatible
N/A
-
External Media player Attachable
N/A
SOFTWARE COMPATIBILITY
-
OLED SuperSign
Yes
-
SuperSign C
Yes
To access more technical documentation and resources, please visit the LG B2B partner portal.
