Semua Spesifikasi
PHYSICAL PARAMETERS
-
Pixel Configuration
-
1R, 1G, 1B (Chip on Board)
-
Pixel Pitch(mm)
-
0.93
-
Module Resolution (WxH)
-
160 x 180
-
Module Dimensions(WxH,mm)
-
150 x 168.8
-
Weight per Module (g)
-
150
-
No. of Modules per Cabinet (WxH)
-
8 (4x2)
-
Cabinet Resolution (WxH)
-
640 x 360
-
Cabinet Dimensions (W x H x D, mm)
-
600 x 337.5 x 44.9
-
Cabinet Surface Area (㎡)
-
0.203
-
Weight per Cabinet (kg/Cabinet)
-
7.0
-
Weight per Square Meter (kg/m²)
-
34.6
-
Physical Pixel Density (pixels/m²)
-
1,137,778
-
Flatness of Cabinet (mm)
-
±0.5 mm
-
Cabinet Material
-
Die-casting Aluminum
-
Service access
-
Front and Rear (Module : Front Only)
OPTICAL SPECIFICATIONS
-
Brightness (Peak/Max, After Calibration)
-
1,200 / 600
-
Color Temperature (Default, Adjustable2))
-
7,300/3,200~9,300K (Adjustable via LG LED Assistant on PC)
-
Visual Viewing Angle (Horizontal)
-
160°
-
Visual Viewing Angle (Vertical)
-
160°
-
Brightness Uniformity
-
95%
-
Color Uniformity
-
±0.02Cx, Cy
-
Contrast Ratio (10 lux)
-
150,000:1
-
Processing Depth (bit)
-
20
-
HDR Compatibility
-
HDR10, HDR10 Pro1)
ELECTRICAL SPECIFICATIONS
-
Driver-IC Type
-
Common Cathode
-
Power Consumption (W/Cabinet, Max.)
-
125
-
Power Consumption (W/Cabinet, Avg.)
-
85
-
Power Consumption (W/㎡, Max.)
-
617
-
Power Consumption (BTU/h/Cabinet, Max.)
-
427
-
Power Consumption (BTU/h/Cabinet, Avg.)
-
290
-
Power Consumption (BTU/h/m², Max.)
-
2,108
-
Power Supply (V)
-
100 to 240
-
Frame Rate (Hz)
-
50 / 60
-
Refresh Rate (Hz)
-
3,840
-
Lifetime (Hours to Half Brightness)
-
100,000
-
Operating Temperature(℃)
-
0∘ to +40∘
-
Operating Humidity
-
10-80 %RH
-
IP Rating Front
-
IP50
-
IP Rating Rear
-
IP20
CERTIFICATION
-
Certification
-
Safety 60950-1,
EMC Class A, BS476 Part 7 Class 1
ENVIRONMENT
-
Environment
-
RoHS
OPTIONAL ACCESSORY
-
Optional Accessory
-
Wall Mount Kit, Frame Kit
CONTROLLER
-
Controller
-
CSAB-009X
