Kasus 1 (V, Phase, Hz)
50/60 Hz 380-415 V 3N~
Batas Rentang Tegangan (Kasus 1) (V)
342 - 456
Kasus 2 (V, Phase, Hz)
60 Hz 380 V 3N~
Batas Rentang Tegangan (Kasus 2) (V)
342 - 418
Terukur (kW)
33.6
Terukur (Btu/h)
114600
Terukur (kW)
8.90
EER (Terukur) (W/W)
3.78
Terukur
0.93 / -
Tipe
Propeller fan
Laju Aliran Udara (Tinggi) (m³/min x No.)
240 x 1
Arah pembuangan (Samping/Atas)
TOP
Tipe
BLDC
Penggerak
DC INVERTER
Output (W x No.)
1200 x 1
Tipe
Hermetically Sealed Scroll
Perpindahan Piston (cm³/rev)
62.1
Jumlah Putaran (rev./min)
3600
Output Motor (W x No.)
5300 x 1
Metode Awal
Inverter
Jenis Oli
FW68L(PVE)
Tipe
Fin & Tube
No.
1
Jenis Sirip
Wide Louver Plus
Net(W x H x D) (mm)
930 x 1690 x 760
Shipping(W x H x D) (mm)
960 x 1825 x 796
Net (kg)
164
Shipping (kg)
174
Warna
Morning Gray / Dawn Gray
RAL (Klasik)
RAL 7038 / RAL 7037
Pencegahan Tekanan Tinggi
High pressure sensor / High pressure switch
Kontrol Suhu Pelepasan
O
Perlindungan Kompresor/Kipas
Over-heat protection / Fan driver overload protector
Perlindungan Inverter
Over-heat protection / Over-current protection
Tipe
R410A
Jumlah yang sudah diisi sebelumnya (kg)
4.7
GWP (Potensi Pemanasan Global)
2087.5
t-CO₂ eq.
9.811
Jenis Kontrol
Electronic Expansion Valve
Cairan (mm(inch))
Φ12.7 (1/2)
Gas (mm(inch))
Φ28.58 (1-1/8)
Cairan
Brazing
Gas
Brazing
Pendinginan / Pemanasan (dB(A))
59 / -
Standar Pengukuran (Tingkat Tekanan)
ISO 3745
Pendinginan / Pemanasan (dB(A))
79 / -
Standar Pengukuran (Tingkat Daya)
ISO 9614
Kabel Komunikasi (VCTF-SB) (mm² × cores)
1.0~1.5 X 2C
Ampere Sirkuit Minimum (MCA) (A)
23.3
Ampere Sekring Maksimum (MFA) (A)
25
Total Arus Lebih Ampere (TOCA) (A)
25
Comp_Arus Awal Maksimum (MSC) (A)
5.9
Comp_Beban Ampere Terukur (Pendinginan) (A)
12.0
Motor Kipas Outdoor_Ampere Beban Penuh (FLA) (A)
2.5
Maks. (Bersyarat) (EA)
20(30)
