Kasus 1
50/60 Hz 220-240 V~
Batas Rentang Tegangan (Kasus 1) (V)
240, 230, 220
Kasus 2
50/60 Hz 220-240 V~
Nominal (kW)
9.00
Nominal (Btu/h)
30700
Nominal (kW)
10.0
Nominal (Btu/h)
34100
H/M/L (W)
48 / 36 / 25
H/M/L (A)
0.43 / 0.34 / 0.25
Tipe
3D Turbo Fan
Laju Aliran Udara (H/M/L) (m³/min)
21 / 19 / 16
Tipe
Brushless DC
Penggerak
Direct
Output (W)
51
Output (No.)
1
Baris x Kolom x FPI
3 x 8 x 21
No.
1
Area Muka (m²)
0.33
Net (kg)
21
Shipping (kg)
26
Warna
White
RAL (Klasik)
RAL 9003
Tipe
Long life filter
Kontrol Suhu
Microprocessor, Thermostat for cooling and heati
Bahan Penyerap Suara / Isolasi Termal
Foamed polystrene
Sekring
Fuse
Tipe
R410A/R32
Jumlah Pengisian Tambahan (kg(each))
0.32 / 0.26
Jenis Kontrol
EEV
O.D / I.D (mm(inch))
32/25
Cairan (mm(inch))
Φ9.52 (3/8)
Gas (mm(inch))
Φ15.88 (5/8)
Cairan
Flare
Gas
Flare
Pendinginan((SH)/H/M/L) (dB(A))
- / 43 / 40 / 36
Pemanasan((SH)/H/M/L) (dB(A))
43 / 40 / 36
Pendinginan((SH)/H/M/L) (dB(A))
- / 53 / 50 / 45
Pemanasan((SH)/H/M/L) (dB(A))
53 / 50 / 45
Kabel Komunikasi (VCTF-SB) (mm² × cores)
1.0~1.5 x 2
Ampere Sirkuit Minimum (MCA) (A)
1.23
Motor Kipas Indoor_Full Load Ampere (FLA) (A)
0.98
Net(W x H x D) (mm)
840 x 204 x 840
Shipping(W x H x D) (mm)
922 x 276 x 917
Tipe
Dual Vane
