Kasus 1
50/60 Hz 220-240 V~
Batas Rentang Tegangan (Kasus 1) (V)
198~242
Kasus 2
50/60 Hz 220-240 V~
Nominal (kW)
10.60
Nominal (Btu/h)
36200
Nominal (kW)
11.9
Nominal (Btu/h)
40600
H/M/L (W)
69 / 49 / 37
H/M/L (A)
0.62 / 0.46 / 0.36
Tipe
3D Turbo Fan
Laju Aliran Udara (H/M/L) (m³/min)
29 / 26 / 22
Tipe
Brushless DC
Penggerak
Direct
Output (W)
135
Output (No.)
1
Baris x Kolom x FPI
3 x 12 x 21
No.
1
Area Muka (m²)
0.50
Net(W x H x D) (mm)
840 x 288 x 840
Shipping(W x H x D) (mm)
922 x 360 x 917
Net (kg)
27
Shipping (kg)
31.5
Warna
White
Tipe
Long life filter
Kontrol Suhu
Microprocessor, Thermostat for cooling and heating
Bahan Penyerap Suara / Isolasi Termal
Foamed polystrene
Tipe
R410A/R32
Jumlah Pengisian Tambahan (kg(each))
0.49 / 0.41
Jenis Kontrol
EEV
O.D / I.D (mm(inch))
32 / 25
Cairan (mm(inch))
Φ9.52 (3/8)
Gas (mm(inch))
Φ15.88 (5/8)
Cairan
Flare
Gas
Flare
Pendinginan((SH)/H/M/L) (dB(A))
- / 43 / 40 / 37
Pemanasan((SH)/H/M/L) (dB(A))
- / 43 / 40 / 37
Pendinginan((SH)/H/M/L) (dB(A))
- / 54 / 51 / 47
Pemanasan((SH)/H/M/L) (dB(A))
- / 54 / 51 / 47
Kabel Komunikasi (VCTF-SB) (mm² × cores)
1.0~1.5 x 2
Ampere Sirkuit Minimum (MCA) (A)
2.29
Motor Kipas Indoor_Full Load Ampere (FLA) (A)
1.83
Tipe
Dual Vane
