Floor Standing, Unit Indoor, 48kBtu/h

Fitur

Galeri

Spesifikasi

Dukungan

Sumber daya

Temukan dealer

Floor Standing, Unit Indoor, 48kBtu/h

Floor Standing, Unit Indoor, 48kBtu/h

ARNU48GPTA4
  • LG Floor Standing ARNU48GPTA4 berbentuk persegi panjang tinggi dan memiliki saluran keluar udara dengan filter di bagian atas dan bawah.
LG Floor Standing ARNU48GPTA4 berbentuk persegi panjang tinggi dan memiliki saluran keluar udara dengan filter di bagian atas dan bawah.

Fitur Utama

  • Desain yang Penuh Gaya
  • Aliran Udara Kuat

Desain yang Penuh Gaya

AC LG Floor Standing yang memenangkan Red Dot Design Award ini sangat ideal untuk interior modern di ruang komersial mana pun.

Aliran Udara Kuat

AC LG Floor Standing sangat ideal untuk ruang komersial dan pabrik berkat aliran udaranya yang cepat dan kuat yang dapat langsung menjangkau hingga jarak 20 meter.

Cetak

Semua Spesifikasi

SUMBER LISTRIK

  • Kasus 1

    50/60 Hz 220-240 V~

  • Batas Rentang Tegangan (Kasus 1) (V)

    198-264

KAPASITAS PENDINGINAN

  • Nominal (kW)

    14.10

  • Nominal (Btu/h)

    48100

  • Panas Sensitif (kW)

    9.30

  • Panas Sensitif (Btu/h)

    31733

KAPASITAS PEMANASAN

  • Nominal (kW)

    15.9

  • Nominal (Btu/h)

    54200

INPUT DAYA (INDOOR)

  • H/M/L (W)

    190 / 140 / 110

KIPAS INDOOR

  • Tipe

    Blower Fan

  • Laju Aliran Udara (Pendinginan,(SH)/H/M/L) (m³/min)

    37 / 33 / 28 / 24

  • Laju Aliran Udara (Pemanasan,(SH)/H/M/L) (m³/min)

    37 / 33 / 28 / 24

  • Kisaran Laju Aliran Udara (Min~Maks) (m³/min)

    24~37

MOTOR KIPAS INDOOR

  • Tipe

    BLDC

  • Penggerak

    Direct

  • Output (W)

    224

  • Output (No.)

    1

PENUKAR PANAS

  • Baris x Kolom x FPI

    3 x 38 x 19

  • No.

    1

  • Area Muka (m²)

    0.39

DIMENSI

  • Net(W x H x D) (mm)

    590 x 1840 x 440

  • Shipping(W x H x D) (mm)

    690 x 1940 x 531

BERAT

  • Net (kg)

    49

  • Shipping (kg)

    58

EKSTERIOR

  • Warna

    Noble White

  • RAL (Klasik)

    RAL 9016

FILTER UDARA

  • Tipe

    Longlife

KONTROL SUHU

  • Kontrol Suhu

    Microprocessor, Thermostat for cooling and heating

BAHAN PENYERAP SUARA / ISOLASI TERMAL

  • Bahan Penyerap Suara / Isolasi Termal

    Foamed polystyrene

PERANGKAT PERLINDUNGAN

  • Sekring

    O

REFRIGERAN

  • Tipe

    R410A

  • Jumlah Pengisian Tambahan (kg(each))

    0.59 / 0.49

  • Jenis Kontrol

    EEV

PIPA PEMBUANGAN (DRAINASE ALAMI)

  • O.D / I.D (mm(inch))

    - / 19, 17

PIPA KONEKTOR

  • Cairan (mm(inch))

    Φ9.52 (3/8)

  • Gas (mm(inch))

    Φ15.88 (5/8)

JENIS KONEKTOR PIPA

  • Cairan

    Flare

  • Gas

    Flare

TINGKAT TEKANAN SUARA (UNIT INDOOR)

  • Pendinginan((SH)/H/M/L) (dB(A))

    54 / 51 / 49 / 45

  • Pemanasan((SH)/H/M/L) (dB(A))

    54 / 51 / 49 / 45

STANDAR PENGUKURAN (TINGKAT TEKANAN)

  • Standar Pengukuran (Tingkat Tekanan)

    ISO 3745

KABEL KONEKTOR

  • Kabel Komunikasi (VCTF-SB) (mm² × cores)

    1.0~1.5 x 2C

KARAKTERISTIK LISTRIK

  • ‬Ampere Sirkuit Minimum (MCA) (A)‭

    1.63

  • Motor Kipas Indoor_Full Load Ampere (FLA) (A)

    1.63

PRODUK

  • Tipe

    Floor Standing

Untuk mengakses lebih banyak dokumentasi teknis dan sumber daya, silakan kunjungi Portal Mitra LG B2B.
