Capacity Cooling (Min.∼Rated) - ㎾
18.8 ~ 46.9
Capacity Cooling (Min.∼Rated) - Btu/h
64,200 ~ 160,000
Power Input Cooling (Rated) - ㎾
16.1
Running Current Cooling (Rated) - A
22.0
Power Input - W
660
Running Current - A
3.0
Power Supply - V, Ø, ㎐
220-240, 1, 50
220, 1, 60
Dimensions Body (W x H x D) - mm
1,558 × 1,920 × 700
Dimensions Body (W x H x D) - inch
61-11/32 x 75-19/32 x 27-9/16
Net Weight Body - ㎏ (lbs)
237.0 (522.5)
Heat Exchanger (Row x Column x Fins per inch) x No.
(4 x 34 x 21) x 1
Heat Exchanger Face Area - ㎡ (ft²)
0.98 (10.54)
Fan Type
Sirocco Fan
Fan Air Flow Rate (H / L) - ㎥/min
120.0 / 95.0
Fan Air Flow Rate (H / L) - ft³/min
4,238 / 3,355
Fan Motor Type
BLDC
Fan Motor Output - W x No.
750 × 2
Sound Pressure Level (H / L) - dB(A)
64 / 57
Piping Connections Liquid Side - ㎜(inch)
Ø 15.88 (5/8)
Piping Connections Gas Side - ㎜(inch)
Ø 28.58 (1-1/8)
Piping Connections Drain Pipe (O.D. / I.D.) - ㎜(inch)
Ø 21.0(13/16) / 17.0(21/32)
Safety Devices
Fuse
Thermal Protector for Fan Motor
Communication Cable - No. x ㎟(AWG)
2C × 1.0~1.5 (H07RN-F)
Power and Communication Cable (included Earth) - No. x ㎟ (AWG)
3C × 2.5 (H07RN-F)
Capacity Cooling (Min.∼Rated) - ㎾
18.8 ~ 46.9
Capacity Cooling (Min.∼Rated) - Btu/h
64,200 ~ 160,000
Power Input Cooling (Rated) - ㎾
16.1
Running Current Cooling (Rated) - A
22.0
Power Supply - V, Ø, Hz
380-415, 3, 50
380, 3, 60
Casing Color
Warm Gray / Morning Gray
Dimensions Body (W x H x D) - ㎜
1,240 × 1,680 × 760
Dimensions Body (W x H x D) - inch
48-13/16 x 66-5/32 x 29-29/32
Net Weight - ㎏ (lbs)
270.0 (595.2)
Heat Exchanger (Row x Column x Fins per inch) x No.
(2 x 58 x 14) x 1
Compressor Type
Hermetic Motor Compressor
Compressor Model - Model x No.
JQA048MAC x 2
Compressor Motor type
BLDC
Compressor Motor Output - W × No.
4,200 x 2
Fan Type
Propeller
Fan Air Flow Rate - ㎥/min
290
Fan Motor Type
BLDC
Fan Motor Output - W x No.
900.0 x 2
Sound Pressure Level Cooling (Rated) - dB(A)
64
Piping Connections Liquid Side (Outer Dia.) - ㎜(inch)
Ø 15.88 (5/8)
Piping Connections Gas Side (Outer Dia.) - ㎜(inch)
Ø 28.58 (1-1/8)
Piping Length (Max.) - m(ft)
50 (164.0)
Refrigerant Type
R410A
Refrigerant Precharged Amount - g(oz)
10,000 (352.7)
Refrigerant Chargeless-Pipe Length - m(ft)
5.0 (16.4)
Refrigerant Additional Charging Volume - g/m(oz/ft)
150 (1.61)
Refrigerant Control
Electronic Expansion Valve
Refrigerant Oil Type
FVC68D(PVE)
Refrigerant Oil Charged volume - cc x No.
3,600 x 2
Wiring Connections Power Supply Cable (included Earth) - No. x ㎟ (AWG)
5C x 6.0 (10)
Maximum Height Difference Outdoor Unit ~ Indoor Unit (Max.) - m
30 (98.4)
Operation Range (Outdoor Temperature) Cooling (Min. ~ Max.) - ℃ DB(℉ DB)
-10 (14.0) ~ 48 (118.4)
