Capacity Cooling (Min.∼Rated∼Max.) - ㎾
2.11 ~ 7.03 ~ 7.47
Capacity Cooling (Min.∼Rated∼Max.) - Btu/h
7,200 ~ 24,000 ~ 25,500
Power Input Cooling (Rated) - ㎾
2.34
Running Current Cooling (Rated) - A
10.20
EER / COP - w/w
3.01
Power Supply - V, Ø, ㎐
220-240, 1, 50/60
Casing Color
Noble White
Dimensions Body (W x H x D) - mm
530 × 1,800 × 295
Dimensions Shipping (W x H x D) - mm
616 x 1,873 x 398
Weight Body - kg (lbs)
25.3 (55.8)
Weight Shipping - ㎏ (lbs)
31.6 (69.7)
Heat Exchanger (Row x Column x Fins per inch) x No.
(2 x 30 x 19) x 1
Heat Exchanger Face Area - ㎡ (ft²)
0.24 (2.58)
Fan Type
Turbo Fan
Fan Air Flow Rate (SH / H / M / L) - ㎥/min
15.0 / 12.0 / - / 10.0
Fan Motor Type
BLDC
Fan Motor Drive
Direct
Fan Motor Output - W x No.
104 x 1
Dehumidification Rate - ℓ/h (pts/h)
3.0 (6.3)
Sound Pressure Level Cooling (SH / H / M / L) - dB(A)
45 / 43 / - / 41
Piping Connections Liquid Side - ㎜(inch)
Ø 9.52 (3/8)
Piping Connections Gas Side - ㎜(inch)
Ø 15.88 (5/8)
Piping Connections Drain Pipe (O.D. / I.D.) - ㎜(inch)
Ø 21.0(13/16) / 17.0(21/32)
Safety Devices
Fuse
Power and Communication Cable (included Earth) - No. x ㎟ (AWG)
4C x 0.75 (18)
Capacity Cooling (Min.∼Rated∼Max.) - ㎾
2.11 ~ 7.03 ~ 7.47
Capacity Cooling (Min.∼Rated∼Max.) - Btu/h
7,200 ~ 24,000 ~ 25,500
Power Input Cooling (Rated) - ㎾
2.34
Running Current Cooling (Rated) - A
10.20
EER / COP - w/w
3.01
Power Supply - V, Ø, Hz
220-240, 1, 50/60
Casing Color
Warm Gray
Dimensions Body (W x H x D) - ㎜
870 × 650 × 330
Net Weight - ㎏ (lbs)
41.5 (91.5)
Heat Exchanger (Row x Column x Fins per inch) x No.
(2 x 30 x 21) x 1
Compressor Type
Twin Rotary
Compressor Model - Model x No.
GKT176MAG x 1
Compressor Motor type
BLDC
Compressor Motor Output - W × No.
1,500 x 1
Fan Type
Hubless
Fan Air Flow Rate - ㎥/min x No.
50 x 1
Fan Motor Type
External BLDC
Fan Motor Output - W x No.
85.0 x 1
Sound Pressure Level Cooling (Rated) - dB(A)
53
Piping Connections Liquid Side (Outer Dia.) - ㎜(inch)
Ø 9.52 (3/8)
Piping Connections Gas Side (Outer Dia.) - ㎜(inch)
Ø 15.88 (5/8)
Piping Length (Min./Max.) - m(ft)
5 (16.4) / 50 (164.0)
Refrigerant Type
R410A
Refrigerant Precharged Amount - g(oz)
1,300 (45.9)
Refrigerant Chargeless-Pipe Length - m(ft)
15.0 (49.2)
Refrigerant Additional Charging Volume - g/m(oz/ft)
30 (0.32)
Refrigerant Control
Electronic Expansion Valve
Refrigerant Oil Type
FVC68D
Refrigerant Oil Charged volume - cc x No.
670 x 1
Wiring Connections Power Supply Cable (included Earth) - No. x ㎟ (AWG)
3C x 4.0 (10)
Maximum Height Difference Outdoor Unit ~ Indoor Unit (Max.) - m(ft)
30 (98.4)
Operation Range (Outdoor Temperature) Cooling (Min. ~ Max.) - ℃ DB(℉ DB)
-5 (23.0) ~ 46 (114.8)
