Cooling(Nom) - kW
5.6
Cooling(Nom) - kcal/h
4,800
Cooling(Nom) - Btu/h
19,100
Heating(Nom) - kW
6.3
Heating(Nom) - kcal/h
5,400
Heating(Nom) - Btu/h
21,500
Power Input(H / M / L) - W
103 / 90 / 78
Casing
Galvanized Steel Plate
Body - ㎜
882 x 260 x 450
Body - inch
34-23/32 x 10-1/4 x 17-23/32
Rows x Columns x FPI
3 x 10 x 21
Face Area - ㎡
0.15
Type
Sirocco Fan
Motor Output × Number - W
154
Running Current - A
1.06
Air Flow Rate(H / M / L) (High Mode-Factory Set) - m³/min
13.0 / 11.3 / 9.6
Air Flow Rate(H / M / L) (High Mode-Factory Set) - ft³/min
459 / 399 / 339
External Static Pressure (High Mode) - ㎜Aq(Pa)
8 (78)
Air Flow Rate (H / M / L) (Standard Mode) - m³/min
13.2 / 11.7 / 7.3
Air Flow Rate (H / M / L) (Standard Mode) - ft³/min
466 / 413 / 258
External Static Pressure (Standard Mode) - ㎜Aq(Pa)
6 (59)
Drive
Direct
Motor type
BLDC
Temperature Control
Microprocessor, Thermostat for cooling and heating
Sound Absorbing Thermal Insulation Material
Foamed polystyrene
Safety Device
Fuse
Liquid Side - ㎜(inch)
Ø 6.35 (1/4)
Gas Side - ㎜(inch)
Ø 12.7 (1/2)
Drain Pipe(Internal Dia.) - ㎜(inch)
Ø 25 (1)
Body - kg(lbs)
26.5 (58.4)
H / M / L - dB(A)
30 / 29 / 26
H / M / L - dB(A)
55 / 54 / 53
Power Supply - Ø, V, Hz
1, 220-240, 501, 220, 60
Refrigerant Control
EEV
Transmission Cable - mm² × Cores
1.0 ~ 1.5 × 2C
