Semua Spesifikasi
SUMBER LISTRIK
-
Kasus 1
-
50/60 Hz 220-240 V~
-
Batas Rentang Tegangan (Kasus 1) (V)
-
220-240
KAPASITAS PENDINGINAN
-
Nominal (kW)
-
5.60
-
Nominal (Btu/h)
-
19100
KAPASITAS PEMANASAN
-
Nominal (kW)
-
6.30
-
Nominal (Btu/h)
-
21500
INPUT DAYA (INDOOR)
-
H/M/L (W)
-
23 / 20 / 17
ARUS OPERASI (INDOOR)
-
H/M/L (A)
-
0.28 / 0.23 / 0.18
KIPAS INDOOR
-
Tipe
-
Cross Flow Fan
-
Laju Aliran Udara (Pendinginan,(SH)/H/M/L) (m³/min)
-
- / 13.5 / 12.5 / 12 .0
-
Laju Aliran Udara (Pemanasan,(SH)/H/M/L) (m³/min)
-
13.5 / 12.5 / 12 .0
MOTOR KIPAS INDOOR
-
Tipe
-
BLDC
-
Penggerak
-
Direct
-
Output (W)
-
85.9
-
Output (No.)
-
1
PENUKAR PANAS
-
Baris x Kolom x FPI
-
3 × 18 × 18
-
No.
-
1
-
Area Muka (m²)
-
0.32
DIMENSI
-
Net(W x H x D) (mm)
-
1200 x 235 x 690
BERAT
-
Net (kg)
-
29.0
-
Shipping (kg)
-
36.0
EKSTERIOR
-
Warna
-
Galvanized Steel Plate + Painting
KONTROL SUHU
-
Kontrol Suhu
-
Microprocessor, Thermostat for cooling and heating
BAHAN PENYERAP SUARA / ISOLASI TERMAL
-
Bahan Penyerap Suara / Isolasi Termal
-
Foamed polystrene
PERANGKAT PERLINDUNGAN
-
Sekring
-
Fuse
REFRIGERAN
-
Tipe
-
R410A
-
Jumlah Pengisian Tambahan (kg(each))
-
0.53
-
Jenis Kontrol
-
EEV
PIPA PEMBUANGAN (MENGGUNAKAN POMPA PEMBUANGAN)
-
O.D / I.D (mm(inch))
-
Ø 25.0 / 16.0
PIPA KONEKTOR
-
Cairan (mm(inch))
-
Φ6.35 (1/4)
-
Gas (mm(inch))
-
Φ12.7 (1/2)
JENIS KONEKTOR PIPA
-
Cairan
-
Flare
-
Gas
-
Flare
TINGKAT TEKANAN SUARA (UNIT INDOOR)
-
Pendinginan((SH)/H/M/L) (dB(A))
-
-/ 36 / 34 / 33
-
Pemanasan((SH)/H/M/L) (dB(A))
-
36 / 34 / 33
STANDAR PENGUKURAN (TINGKAT TEKANAN)
-
Standar Pengukuran (Tingkat Tekanan)
-
ISO 3745
TINGKAT DAYA SUARA (UNIT INDOOR)
-
Pendinginan((SH)/H/M/L) (dB(A))
-
-/ 61 / 59 / 56
-
Pemanasan((SH)/H/M/L) (dB(A))
-
61 / 59 / 56
STANDAR PENGUKURAN (TINGKAT DAYA)
-
Standar Pengukuran (Tingkat Daya)
-
ISO 3741
KABEL KONEKTOR
-
Kabel Komunikasi (VCTF-SB) (mm² × cores)
-
1.0 ~ 1.5 × 2C
KARAKTERISTIK LISTRIK
-
Ampere Sirkuit Minimum (MCA) (A)
-
1.21
-
Motor Kipas Indoor_Full Load Ampere (FLA) (A)
-
0.97
