Kasus 1 (V, Phase, Hz)
50 Hz 380-415 V 3N~
Kasus 2 (V, Phase, Hz)
380 V 3N~ 60 Hz
Terukur (kW)
22.4
Terukur (Btu/h)
76400
Terukur (kW)
25.2
Terukur (Btu/h)
86000
Terukur (kW)
5.89
EER (Terukur) (W/W)
4.06
COP (Terukur) (W/W)
4.47
Terukur
0.93/0.93
Tipe
Propeller fan
Laju Aliran Udara (Tinggi) (m³/min x No.)
140
Arah pembuangan (Samping/Atas)
Side
Penggerak
DC INVERTER
Output (W x No.)
124 x 2
Tipe
Hermetically Sealed Scroll
Output Motor (W x No.)
4,200 x 1
Jenis Oli
FVC68D(PVE)
Jenis Sirip
Wide Louver Plus
Net(W x H x D) (mm)
950 × 1,380 × 330
Net (kg)
115
Pencegahan Tekanan Tinggi
High pressure sensor / High pressure switch
Perlindungan Kompresor/Kipas
Over-heat protection / Over-current protection
Perlindungan Inverter
Over-heat protection / Over-current protection
Tipe
R410A
Jumlah yang sudah diisi sebelumnya (kg)
3.5
Jenis Kontrol
Electronic Expansion Valve
Cairan (mm(inch))
Φ9.52 (3/8)
Gas (mm(inch))
Φ19.05 (3/4)
Pendinginan / Pemanasan (dB(A))
57/57
Pendinginan / Pemanasan (dB(A))
69/69
Kabel Komunikasi (VCTF-SB) (mm² × cores)
1.0~1.5 x 2
Maks. (Bersyarat) (EA)
13
