All Spec
PANEL
-
Screen Size
98"
-
Panel Technology
IPS
-
Aspect Ratio
16:9
-
Native Resolution
3,840 x 2,160 (UHD)
-
Brightness (Typ.)
500 cd/m²
-
Contrast Ratio
1,300:1
-
Viewing Angle (H x V)
178 × 178
-
Response Time
8ms (G to G)
-
Surface Treatment (Haze)
Haze 1%
-
Life Time (Typ.)
50,000 hrs
-
Operation Hours
24 Hrs
-
Orientation
Landscape & Portrait
CONNECTIVITY
-
Input
HDMI (3), DP, DVI-D, Audio, USB 2.0 (2) *
-
Output
DP, Audio (Off/Fixed/Variable), Externel Speaker
-
External Control
RS232C In/out, RJ45 In, IR In
KEY FEATURE
-
Key Feature
Internal Memory 8GB (System 4GB + Available 3.6GB), Built-in Wi-Fi, Temperature Sensor, Auto Brightness Sensor, Current Sensor, webOS 4.0, Embedded CMS (USB Auto Playback, Local Contents Scheduling, Group Manager), Image Customis ation, Content Sync (RS232C, Local Network), Screen Share, Play via URL, OSD Rotation, Content Rotation, PIP/ PBP(4), Tile Mode Setting (Max 15x15), Setting Data Cloning, Firmware Update by Network, SNMP 1.4, ISM Mode, Crestron ConnectedⓇ2), Cisco Compatibility 3), Beacon, HDMI-CEC4), SI Server Setting, webRTC
ENVIRONMENTAL CONDITIONS
-
Operation Temperature
0°C to 40°C
-
Operation Humidity
10% to 80%
POWER
-
Power Type
100-240V~, 50/60Hz
-
Power Supply
Built-In Power
-
Power Consumption-Typ. / Max.
TBD / TBD
-
Power Consumption - Smart Energy Saving
TBD
CERTIFICATION
-
Safety
CB / NRTL
-
EMC
AS/NZS CISPR32,RCM(Class A)
-
ErP
Yes(EU Only)
SOFTWARE COMPATIBILITY5)
-
Content Management Software
SuperSign CMS
-
Control and Monitoring Software
SuperSign Control/Control+
ACCESSORIES
-
Basic
Remote Controller (2ea Batteries Included), Power Cord, QSG, IR/Light Sensor Receiver, DP Cable (1.8M), Regulation Book, Phone to RS232C Gender, EYE-BOLT
-
Optional
Speaker (SP-2200)
