- Resolution : 1,920 × 1,080 (FHD)
- Brightness : 200 / 600 nit (APL 100% / 25%, without Glass)
- Transparency : 43% (Set)
- Bezel Width : Even 12.2mm (T/R/L/B)
All Spec
PANEL
Screen Size (Inch)
55"
Panel Technology
OLED
Back Light Type
OLED
Aspect Ratio
16:9
Native Resolution
1920x1080 (FHD)
Refresh Rate
120 Hz
Brightness
200/600nit (APL 100%/25%, Without Glass)
Contrast Ratio
200,000 : 1
Color Gamut
DCI 90%, BT709 110%
Viewing Angle (H x V)
178x178
Color Depth (Number of Colors)
10bit(R), 1.07Bilion colors
Response Time
0.1ms (G to G), 8ms (MPRT)
Surface Treatment (Haze)
Haze 3% (SET), Hard coating (5H)
Life time
30,000 Hrs (Typ.)
Operation Hours (Hours/Day)
18/7 (Moving Content Only)
Portait / Landscape
Yes / Yes
Transparency
43% (SET)
PROTECTION GLASS
Thickness
3.0mm
Tempered / Chemical strengthening
Chemical strengthening
Anti-Reflective
Yes (Film)
Shatter-Proof
Yes
ENVIRONMENT CONDITIONS
Operation Temperature
0 °C to 40 °C
Operation Humidity
10 % to 80 %
POWER
Power Supply
AC 100-240V~, 50/60Hz
Power Type
Built-In Power
POWER CONSUMPTION
Typ.
70W (IEC 62087)
Max.
230W
BTU (British Thermal Unit)
239 BTU/Hr(Typ), 785 BTU/Hr(Max.)
Smart Energy Saving (70%)
0.5W
Power off
0.5W
CERTIFICATION
Safety
CB / NRTL
EMC
FCC Class "A" / CE / KC
ERP / Energy Star
Yes / No
SOFTWARE COMPATIBILITY
SuperSign CMS
Yes
SuperSign Control+
Yes
SuperSign Cloud
Yes
Mobile CMS
Yes
Connected Care
Yes
LANGUAGE
OSD
English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Polski, Türkçe, Arabic
ACCESSORY
Basic
Remote Controller(include battery 2ea), Power Cord, QSG, IR receiver, Regulation Book, Phone to RS232C Gender, MCX/Harness Cables(3000mmx4ea/3000mmx2ea) for connection between panel and Signage Box), DP Cable(2M), LAN Cable(1.5M), RS232 Cable(4P-4P,1.5M), LC Cable(VLC,3M), Screw(M3xL5.5 Black,24EA / M3xL5.5 Silver,8EA / M3xL6 Black, 14EA), Cover Shield Assy 1EA, Cable Rubber 2EA, Cable Cap Assy 2EA, Tiling Bracket 2EA, Signage Box Wing Bracket 2EA
SPECIAL FEATURE
Conformal Coating (Power Board)
Yes
