Concealed Duct, Mid/High Static (Slim), Unit Indoor, 28kBtu/h

Concealed Duct, Mid/High Static (Slim), Unit Indoor, 28kBtu/h

Concealed Duct, Mid/High Static (Slim), Unit Indoor, 28kBtu/h

ARNU28GM2A4
Front view of Concealed Duct, Mid/High Static (Slim), Unit Indoor, 28kBtu/h ARNU28GM2A4
Front view of Concealed Duct, Mid/High Static (Slim), Unit Indoor, 28kBtu/h ARNU28GM2A4

Fitur Utama

  • Operasi Ruangan Ganda
  • Kontrol External Static Pressure (ESP)
  • Kontrol Dua Termistor

Operasi Ganda

Dimungkinkan untuk mengoperasikan pendinginan dan pemanasan pada beberapa ruang secara bersamaan dengan menggunakan spiral duct (tipe tertanam atau fleksibel dan ruang aliran).

Kontrol ESP

Pengguna memiliki akses mudah ke pemilihan volume udara melalui kendali jarak jauh dengan menggunakan fungsi kontrol ESP (External Static Pressure/Tekanan Statis Eksternal). Motor BLDC dapat mengendalikan kecepatan kipas dan volume udara.

Kontrol Dua Termistor

Dua termistor mendeteksi perbedaan antara suhu udara langit-langit dan lantai serta mengoptimalkan suhu udara dalam ruangan untuk lingkungan yang lebih nyaman.

Cetak

Semua Spesifikasi

KAPASITAS PENDINGINAN/PEMANASAN

  • Terukur (Btu/h)

    28 000 / 31 500

KIPAS INDOOR

  • Tekanan Statis Eksternal (Min ~ Maks) (mmAq)

    4~18

  • Tekanan Statis Eksternal (Min ~ Maks) (Pa)

    39~176

DIMENSI

  • Net(W x H x D) (mm)

    1250 x 270 x 700

  • Shipping(W x H x D) (mm)

    1450 x 338 x 773

BERAT

  • Net (kg)

    36

KARAKTERISTIK LISTRIK

  • Motor Kipas Indoor_Full Load Ampere (FLA) (A)

    2.3

PRODUK

  • Tipe

    Concealed Duct

Untuk mengakses lebih banyak dokumentasi teknis dan sumber daya, silakan kunjungi Portal Mitra LG B2B.
