ABNQ24GL3A1 / AUUQ24GH2
MSRP Rp

INDOOR SPECIFICATIONS

  • Capacity Cooling (Min.∼Rated∼Max.) - ㎾
    1.9 ~ 7.0 ~ 8.0
    Capacity Cooling (Min.∼Rated∼Max.) - Btu/h
    6,460 ~ 23,880 ~ 27,430
  • Power Input Cooling (Rated) - ㎾
    2.31
    Running Current Cooling (Rated) - A
    10.0 / 14.0
  • Running Current - A
    1.0
    EER / COP - w/w
    3.03
  • SEER / SCOP - Btu/Wh
    16
    Power Supply - V, Ø, ㎐
    220-240, 1, 50
    220, 1, 60
  • Dimensions Body (W x H x D) - mm
    1,000 × 190 × 700
    Dimensions Body (W x H x D) - inch
    43-5/16 x 7-15/32 x 27-9/16
  • Net Weight Body - ㎏ (lbs)
    27.0 (59.5)
    Heat Exchanger (Row x Column x Fins per inch) x No.
    (3 x 11 x 18) x 1
  • Heat Exchanger Face Area - ㎡ (ft²)
    0.21 (2.31)
    Fan Type
    Sirocco Fan
  • Fan Air Flow Rate (H / M / L) - ㎥/min
    20.0 / 16.0 / 12.0
    Fan Air Flow Rate (H / M / L) - ft³/min
    710 / 570 / 430
  • Fan Air Flow Rate (External Static Pressure) - Pa (㎜Aq)
    25 (2.54)
    Fan Motor Type
    BLDC
  • Fan Motor Output - W x No.
    19 x 2
    Dehumidification Rate - ℓ/h (pts/h)
    2.5 (5.3)
  • Sound Pressure Level (H / M / L) - dB(A)
    39 / 35 / 32
    Piping Connections Liquid Side - ㎜(inch)
    Ø 9.52 (3/8)
  • Piping Connections Gas Side - ㎜(inch)
    Ø 15.88 (5/8)
    Piping Connections Drain Pipe (O.D. / I.D.) - ㎜(inch)
    Ø 25.4(1) / 20.4(13/16)
  • Safety Devices
    Fuse
    Power and Communication Cable (included Earth) - No. x ㎟ (AWG)
    4C x 0.75 (18)

OUTDOOR SPECIFICATIONS

  • Capacity Cooling (Min.∼Rated∼Max.) - ㎾
    1.9 ~ 7.0 ~ 8.0
    Capacity Cooling (Min.∼Rated∼Max.) - Btu/h
    6,460 ~ 23,880 ~ 27,430
  • Power Input Cooling (Rated) - ㎾
    2.31
    Running Current Cooling (Rated) - A
    10.0 / 14.0
  • EER / COP - w/w
    3.03
    SEER / SCOP - Btu/Wh
    16
  • Power Supply - V, Ø, Hz
    220-240, 1, 50
    220, 1, 60
    Casing Color
    Warm Gray
  • Dimensions Body (W x H x D) - ㎜
    870 × 655 × 320
    Dimensions Body (W x H x D) - inch
    34-1/4 x 25-25/32 x 12-19/32
  • Net Weight - ㎏ (lbs)
    41.0 (90.4)
    Heat Exchanger (Row x Column x Fins per inch) x No.
    (2 x 30 x 21) x 1
  • Compressor Type
    Twin Rotary
    Compressor Model - Model x No.
    GKT176MBA
  • Compressor Motor type
    BLDC
    Compressor Motor Output - W × No.
    1,500 x 1
  • Fan Type
    Propeller
    Fan Air Flow Rate - ㎥/min x No.
    50 x 1
  • Fan Motor Type
    BLDC
    Fan Motor Output - W x No.
    85.0 x 1
  • Sound Pressure Level Cooling (Rated) - dB(A)
    48
    Piping Connections Liquid Side (Outer Dia.) - ㎜(inch)
    Ø 9.52 (3/8)
  • Piping Connections Gas Side (Outer Dia.) - ㎜(inch)
    Ø 15.88 (5/8)
    Piping Length (Max.) - m(ft)
    50 (164.0)
  • Refrigerant Type
    R410A
    Refrigerant Precharged Amount - g(oz)
    1,000 (35.3)
  • Refrigerant Chargeless-Pipe Length - m(ft)
    15 (49.2)
    Refrigerant Additional Charging Volume - g/m(oz/ft)
    20 (0.22)
  • Refrigerant Control
    Electronic Expansion Valve
    Refrigerant Oil Type
    FVC68D
  • Refrigerant Oil Charged volume - cc x No.
    670 x 1
    Wiring Connections Power Supply Cable (included Earth) - No. x ㎟ (AWG)
    3C x 2.5 (12)
  • Maximum Height Difference Outdoor Unit ~ Indoor Unit (Max.) - m(ft)
    30 (98.4)
    Operation Range (Outdoor Temperature) Cooling (Min. ~ Max.) - ℃ DB(℉ DB)
    -5 (23.0) ~ 48 (118.4)
