ARNU15GL2G4
MSRP Rp

CAPACITY

  • Cooling(Nom) - kW
    4.5
    Cooling(Nom) - kcal/h
    3,900
  • Cooling(Nom) - Btu/h
    15,400
    Heating(Nom) - kW
    5.0
  • Heating(Nom) - kcal/h
    4,300
    Heating(Nom) - Btu/h
    17,100

POWER INPUT

  • Power Input(H / M / L) - W
    56 / 41 / 34

CASING

  • Casing
    Galvanized Steel Plate

DIMENSIONS (W × H × D)

  • Body - ㎜
    900 x 190 x 700
    Body - inch
    35-7/16 × 7-15/32 × 27-9/16

COIL

  • Rows x Columns x FPI
    2 x 11 x 18
    Face Area - ㎡
    0.17

FAN

  • Type
    Sirocco Fan
    Motor Output × Number - W × No.
    19 x 1, 5 x 1
  • Running Current - A
    0.76
    Air Flow Rate(H / M / L) (High Mode-Factory Set) - m³/min
    12.5 / 10.0 / 8.5
  • Air Flow Rate(H / M / L) (High Mode-Factory Set) - ft³/min
    450 / 360 / 310
    External Static Pressure (High Mode) - ㎜Aq(Pa)
    2.54 (25)
  • Air Flow Rate (H / M / L) (Standard Mode) - m³/min
    12.5 / 10.0 / 8.5
    Air Flow Rate (H / M / L) (Standard Mode) - ft³/min
    450 / 360 / 310
  • External Static Pressure (Standard Mode) - ㎜Aq(Pa)
    0 (0)
    Drive
    Direct
  • Motor type
    BLDC

TEMPERATURE CONTROL

  • Temperature Control
    Microprocessor, Thermostat for cooling and heating

SOUND ABSORBING THERMAL INSULATION MATERIAL

  • Sound Absorbing Thermal Insulation Material
    Foamed polystyrene

SAFETY DEVICE

  • Safety Device
    Fuse

PIPE CONNECTIONS

  • Liquid Side - ㎜(inch)
    Ø 6.35 (1/4)
    Gas Side - ㎜(inch)
    Ø 12.7 (1/2)
  • Drain Pipe(Internal Dia.) - ㎜(inch)
    Ø 25.4 (1)

NET WEIGHT

  • Body - kg(lbs)
    23 (50.7)

SOUND PRESSURE LEVELS

  • H / M / L - dB(A)
    33 / 30 / 28

SOUND POWER LEVELS

  • H / M / L - dB(A)
    54 / 51 / 47

POWER SUPPLY

  • Power Supply - Ø, V, Hz
    1, 220-240, 50
    1, 220, 60

REFRIGERANT CONTROL

  • Refrigerant Control
    EEV

TRANSMISSION CABLE

  • Transmission Cable - mm² × Cores
    1.0 ~ 1.5 × 2C
