24CAV37K-B
Kelas 24'' (24.0'' diagonal) Zero Client TERA2 (Seri V)
  • Layar IPS FHD 1920x1080
  • Layar IPS
  • Teradici® Tera2321
  • Ketinggian / Kemiringan / Pivot
Kelas 24" (24.0" diagonal) Zero Client TERA2 (Seri V)
MSRP Rp

PANEL

  • TAA Complaint
    Yes
    Panel Size (measured diagonally)
    24” (23.8”)
  • Processor
    Teradici Tera2321 PCoIP Chip
    RAM
    512MB
  • Protocol
    PCoIP
    Networking
    10 / 100 / 1000
  • Color Depth
    16.7M
    Pixel Pitch(mm)
    0.275(H) x 0.275(V) 0.2652 (H) x 0.2652 (V)
  • Contrast Ratio
    1,000:1 (Typ) 5,000,000:1 (DFC)
    Response Time (on/off)
    14ms (GTG)
  • Viewing Angle (CR≥10)
    178°/178°
    Surface Treatment
    Hard coating, Anti-Glare
  • Aspect Ratio
    16:9
    Brightness (Typ)
    250 cd/m²
  • Color Depth (DFC)
    16.7M
    Panel Type
    AH-IPS
  • Resolution
    1,920 x 1,080

INPUT (SIGNAL)

  • D-Sub
    Yes

OUTPUT (SIGNAL)

  • DVI
    Yes
    Others
    10/100 /1000

INTERACTIVE

  • USB 2.0
    6 (4 Back, 2 Side)

INPUT (AUDIO)

  • Mic In
    Yes

OUTPUT (AUDIO)

  • Headphone Out
    Yes

SYSTEM

  • Networking
    10/100/1000 Ethernet
    Processor
    Teradici Tera2321 PCoIP Chip
  • Memory
    512MB

SPECIAL FEATURE

  • IPS
    Yes
    2.0 USB Input (6)
    Yes
  • UPoE available with AUPoE* Adapter
    Yes

CABINET

  • Color
    Black Texture
    Set (with Stand) (WxHxD)
    22.4” x 13.4” x 2"
  • Set Weight (with Stand)
    12.1 Ibs.
    Set (without Stand) (WxHxD)
    22.4” x 15.3” x10.2”
  • Set Weight (without Stand)
    10.6 Ibs.
    Box (WxHxD)
    25.3" x 7.6" x 16.1"
  • Box Weight
    15.4 Ibs
    Stand
    Base detachable, Tilt, Yes / -5° (front), 35° (rear), Swivel (90°), Height (130mm), Pivot
  • VESA Standard Mount Interface
    100mm x 100mm

STANDARD CERTIFICATIONS

  • UL(cUL)
    Yes
    TUV-Type
    Yes
  • FCC-B, CE
    Yes
    RoHS
    Yes

INPUTS/OUTPUTS

  • USB 2.0
    6 (4 Back, 2 Side)
    Others
    LAN (Ethernet)
  • Headphone Out
    Yes
    DVI-I out (Dual)
    Yes
  • D-sub in
    Yes
    Audio Input (Mic In)
    Yes

SPEAKER

  • Speaker
    Yes (5W x 2)

POWER

  • Type
    Adapter (19V DC)
    Input
    100 ~ 240V
  • Normal On (typ.)
    24W (Monitor) / 29W (Cloud)
    Power Save/Sleep Mode (Max)
    0.5W (Monitor) / 5.5W (Cloud)
  • DC Off (Max)
    0.5W (Monitor) / 0.5W (Cloud)

POWER CONSUMPTION (TYPICAL)

  • Watts in on
    24W(D-sub)/29W(PCoIP)
    Watts in sleep
    0.5W(D-sub)/7W(PCoIP)
  • Watts in off
    0.5W(D-sub)/0.5W(PCoIP)

FREQUENCY

  • H-Frequency (Analog)
    30 kHz ~ 68 kHz
    V-Frequency (Digital)
    57Hz ~ 63Hz

ANALOG FREQUENCY

  • H-Frequency
    30 kHz ~ 68 kHz
    V-Frequency
    57Hz ~ 63Hz

STAND

  • VESA Mount™
    100mm x 100mm
    Pivot
    Yes
  • Base Detchable
    Yes
    Tilt
    -5°(front)/15°(rear)
  • Swivel (Angle)
    90°
    Height (mm)
    130mm

DIMENSIONS

  • Weight Set w/Stand
    12.3 Ibs.
    Weight Set w/o Stand
    7.4 Ibs.
  • Warranty
    3 Years (Parts, Labor, Backlight)
    UPC
    7 19192 19162 4
  • Set w/o Stand (W x H x D)
    21.4" x 13.1" x 1.9"
    Set w/Stand (W x H x D)
    21.4" x 15.2" x 5.1"
  • Box weight
    16.2 lbs
    Box (W x H x D)
    24.3" x 15.9" x 7.8"

WARRANTY

  • Warranty
    3-Year Limited Warranty (Parts/Labor/Backlight)

UPC

  • UPC
    7 19192 19754 1

ACCESSORIES

  • D-Sub
    Yes
    Power Cord
    Yes
