- Efficacité énergétique (contrôle du courant de pointe, échange de chaleur amélioré, verrouillage du mode)
- Large plage de fonctionnement (refroidissement : -10~48, chauffage : -15~18)
- Finition noire résistante à la corrosion
- Refroidissement et chauffage rapides grâce à un système de capteur intelligent
Toutes les caractéristiques
GENERAL
Puissance chaud Max (W)
5390
Puissance froid Max (W)
4720
Dimensions de l'unité extérieure LxHxP (mm)
770 x 545 x 288
Poids de l'unité extérieure (kg)
32.5
Type de fluide frigorigène
R32
Puissance froid Nom/Min (W)
4100/880
Puissance chaud Nom/Min (W)
4690/970
Puissance acoustique en froid (TG,G,M,P,TP)
60
MAX. ADMISSIBLE CAPACITÉ POUR L’UNITÉ INTÉRIEURE INDIVIDUELLE
Max (kBtu/h)
12
CAPACITÉ TOTALE ADMISSIBLE DE L’UNITÉ INTÉRIEURE CONNECTÉE
Max (kBtu/h)
21
CLASSIFICATION
Châssis
U18A
LIMITE DE COMBINAISON
Nombre d’unités intérieures (EA)
2
COMPRESSEUR
Modèle x n°
DST102MA x 1
Sortie moteur (W x No.)
900 x 1
Type de moteur
BLDC
Quantité de charge d’huile (cc x n°)
280 x 1
Type d’huile
FW68D
Type
Twin Rotary
CAPACITÉ DE REFROIDISSEMENT
Min ~ Max (Btu/h)
3,000~16,100
Min ~ Max (kW)
0.88~4.72
Nominal (Btu/h)
14,000
Nominal (kW)
4.10
DIMENSIONS
Net(l x H x P) (mm)
770 x 545 x 288
Expédition(l x H x P) (mm)
920 x 588 x 388
RENDEMENT
COP (W/W)
4.40
EER (W/W)
4.10
EXTÉRIEUR
Couleur
Warm Gray
CAPACITÉ DE CHAUFFAGE
Min ~ Max (Btu/h)
3,300~18,400
Min ~ Max (kW)
0.97~5.39
Nominal (Btu/h)
16,000
Nominal (kW)
4.69
ÉCHANGEUR THERMIQUE
Lignes x Colonnes x Ailettes par pouce
2 × 24 ×14
DIFFÉRENCE DE HAUTEUR MAXIMALE
IDU - IDU(Max) (m)
7.5
IDU - ODU(Max) (m)
15
VENTILATEUR EXTÉRIEUR
Débit d’air (m³/min x NO.)
35.0 x 1
Type
Propeller
MOTEUR DU VENTILATEUR EXTÉRIEUR
Sortie (W x No.)
43.0 x 1
Type
BLDC
DOUILLE DE CONNEXION DE TUYAU
Type de connexion (gaz)
Flare
Type de connexion (liquide)
Flare
Gaz (mm (pouces) x n°)
Ø 9.52(3/8) × 2
Liquide (mm (pouces) x n°)
Ø 6.35(1/4) × 2
LONGUEUR DE TUYAUTERIE
Chaque branche (nominal / max / min) (m)
7.5 / 20 / -
Tuyauterie totale(Max) (m)
30
FACTEUR D’ALIMENTATION (REFROIDISSEMENT/CHAUFFAGE)
Nominal
0.98 / 0.98
ALIMENTATION ÉLECTRIQUE
Limite de la plage de tension(Scénario 1) (V)
198 ~ 264
AGENT FRIGORIGÈNE
Montant de charge supplémentaire (branche) (g/m)
20
Longueur de tuyau sans charge (branche) (m)
30
Type de commande
Electronic Expansion Valve
Précharge (kg)
1.040
Type
R32
t éq. CO₂
0.702
COURANT DE FONCTIONNEMENT
Courant de fonctionnement maximum (A)
11.0
COURANT DE FONCTIONNEMENT (REFROIDISSEMENT)
Min/Max (A)
- / 11.00 (A)
NIVEAU DE PUISSANCE SONORE (UNITÉ EXTÉRIEURE)
Refroidissement / chauffage (dB(A))
60.0 / -
NIVEAU DE PRESSION SONORE (UNITÉ EXTÉRIEURE)
Refroidissement / Chauffage (à une hauteur de 1,5 m) (dB(A))
45.0 / 48.0
COMBINAISON DE TESTS
Combinaison de tests (Modèle x n°)
MJ07PC NSJ x 2EA
POIDS
Net (kg)
32.5
Expédition (kg)
35.2
