Model name
LSCB018-GK
Pixel Configuration
Single SMD
Pixel Pitch (mm)
1.88
Module Resolution (WxH)
160x90
Module Dimensions(WxH,mm)
300x168.75
Weight per Module (kg)
0.4
No. of Modules per Cabinet (WxH)
2x2
Cabinet Resolution (WxH)
320x180
Cabinet Dimensions (W x H x D, mm)
600x337.5x35
Cabinet Surface Area (㎡)
0.2
Weight per Cabinet (kg/unit)
5.2
Weight per Square Meter (kg/㎡)
25.68
Physical Pixel Density (pixels/㎡)
284,444
Flatness of Cabinet (mm)
±0.1
Cabinet material
Die-casting Aluminum
Service access
Front
Max Brightness (After Calibration, nit)
800
Color Temperature (K)
6,500
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
160
Brightness Uniformity(%)
0.97
Color Uniformity
±0.003CxCy
Contrast Ratio
5,000
Processing Depth (bit)
14
Power Consumption (W/Cabinet, Max.)
150
Power Consumption (W/Cabinet, Avg.)
50
Power Consumption (W/㎡, Max.)
740
Heat Dissipation (BTU/h/Cabinet, Max.)
511.8
Heat Dissipation (BTU/h/Cabinet, Avg.)
170.6
Heat Dissipation (BTU/h/㎡, Max.)
2,524.88
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
3,840
LED Lifetime (Half brightness)
100,000
Operating Temperature(℃)
-10∘to +45∘
Operating Humidity
0~80%RH
IP rating Front
IP30
IP rating Rear
IP30
Certification
CE, FCC, ETL, EMC Class-B Fire Protection
Environment
RoHS
Controller
CVCA
90 degree corner cut
O
