Front Control Dishwasher with QuadWash™ and EasyRack™ Plus

Features

Gallery

Specs

Reviews

Support

Front Control Dishwasher with QuadWash™ and EasyRack™ Plus

LDF5545WW

Front Control Dishwasher with QuadWash™ and EasyRack™ Plus

(2)
Global_XD3QuadWash_2017_Feature_01_4Reasons_D

4 Reasons to Buy LG Dishwasher


Global_XD3QuadWash_2017_Feature_02_QuadWash_D

Clean From Every Angle

Achieve maximum cleaning coverage throughout the entire cycle with the new QuadWash™ system. With four spray arms instead of just two, QuadWash™ also includes Multi-Motion arms that rotate back and forth while spinning. The high-pressure jets power-clean dishes from multiple angles to reach every nook and cranny.
LDF-TurboExpressCycle_12-6-18-D1

Turbo and Express Cycles

Turbo Cycle will clean heavily soiled dishes in an hour using slightly more energy and water.*
Express Cycle will quickly clean lightly soiled dishes in 33 minutes.*
LDF-NightExtraDry_12-6-18-D1

More options for better drying

Extra Dry: This option adds extra drying time to the cycle and raises the heated rinse temperature.
Night Dry: Dishes left in the dishwasher overnight after the cycle ends can result in steam inside the tub condensing on dishes, leaving them wet. Night Dry runs the ventilation fan periodically to help vent steam from the tub.
Inverter-DirectDrive-Motor_11022018_D_V

Inverter DirectDrive™ Motor

LG's Inverter Direct Drive Motor was designed with quiet in mind. With fewer moving parts and up to 48dB, you get reliable performance from one of the quietest dishwashers in its class.
Global_XD3QuadWash_2017_Feature_07__EsayRack_D

Easy Loading, Maximum Flexibility

The newly-enhanced EasyRack™ Plus system provides outstanding flexibility and convenience, adjusting to just about any load of dishes to help ensure optimal cleaning performance. Easy to adjust on-the-fly, this racking system can shift to handle any challenge your dishes can serve up.
Global_XD3-QuadWash_2017_Feature_09_Smart-ThinQ_D1

ThinQ®

With the LG ThinQ® smartphone app and NFC Tag On technology, you can download new wash cycles such as pots & pans or casseroles and even download your own personalized cleaning settings. With SmartDiagnosis™ you can troubleshoot any issues that may arise with your dishwasher quickly and efficiently.
Global_XD3QuadWash_2017_Feature_06_DualZoneWash_D

Dual Zone Wash

Gently clean your delicate dishes, while power-washing heavy-duty pots and pans with Dual Zone Wash. This option allows you to vary the spray intensity in the upper and lower racks.
Star_feature_desktop_new_LDT5665ST

Environmentally Friendly

Energy Star® rated, which means it uses less energy than required by current federal standards. Among the most energy-efficient dishwashers in its class.

Alt text

*This cycle does not have drying. Select the Extra Dry and Night Dry option or another cycle for better drying.
It must be between 4 and 40 characters

Headline can be up to 200 characters.

Body text can be up to 1000 characters.
Folding headline text can be up to 200 characters.
Body text can be up to 1000 characters.

Alt text

*NFC Tag On Technology is only available with Android OS.

SUMMARY

Print
CAPACITY
15 Total Place Settings
Dimensions (WxHxD)
23.75" x 33.6" x 24.6
Steam Technology
No
ThinQ®
Yes

All Spec

BASIC SPEC.

Control Panel(Material)

ABS

Handle Type

Pocket Handle

Panel Type

Front Control

Total Place Settings

15

GENERAL

Color

White

Manufacturer

LG

RACK FEATURES

Cutlery Baskets

Yes

EasyRack™ Plus System

Yes

Gliding Type_Lower

Wheel

Height Adjustable 3rd Rack

Yes

Maximum Height of Lower Rack (in)

12.5

Maximum Height of Upper Rack (in)

7.1

CYCLE/OPTION

Number of Wash Cycles (Program)

9 (Auto, Heavy, Delicate, Normal, Turbo, Download Cycle, Machine Clean, Rinse, Express)

Auto

Yes

Heavy

Yes

Delicate

Yes

Normal

Yes

Turbo

Yes

Download Cycle

Yes

Machine Clean

Yes

Express

Yes

Rinse

Yes

Number of Options

8 (Dual Zone, Half Load, Energy Saver, High Temp, Extra Dry, Delay Start, Control Lock, Night Dry)

Dual Zone

Yes

Half Load

Yes

Energy Saver

Yes

High Temp.

Yes

Extra Dry

Yes

Delay Start

Up to 12 hours

Control Lock

Yes

ENERGY/WATER PERFORMANCE

CEE Tier Level

1

Energy Star

Yes

Energy Use (kWh/Year)

258

Water Use (Gallons/Cycle)

2.9

DIMENSIONS / CLEARANCES / WEIGHT

Packing Dimensions - WxHxD (in)

28 1/32 x 34 7/8 x 29 5/8

Packing Weight (lbs)

88.9

Product Dimensions - WxHxD (in)

28 1/32 x 34 7/8 x 29 5/8

Product Weight (lbs)

75.6

APPEARANCE

Rinse Refill Indicator

Yes

Tub Material

NeveRust™ Stainless Steel

KEY FEATURE

Detergent and Rinse-Aid Dispenser

Yes

DirectDrive Motor™

Yes

Drying System

Dynamic Dry™

Hidden Water Heater

Yes

Inverter Direct Drive Motor

Yes

LoDecibel Quiet Operation (dBA)

48

Number of Spray Arms

3 (Top, Upper, Lower)

QuadWash™

QuadWash™

Safety Float Switch (Leaks)

Yes

SenseClean Wash System

Yes

Soil (Turbidity) Sensor

Yes

Vario Washing System

Yes

SMART TECHNOLOGY

Smart Diagnosis

Yes

NFC

Yes
