All specs
ACCESSORY
-
Basic
-
Power Cord 3 M*1, USB Cable(Type A-Type B) 5 M*1, USB Type-C Cable(C to C) 1.8 M*1, HDMI Cable 3 M*1, Writing Pen*2pcs, User Manual, QSG, Carton Box, Remote Controller(include battery 2ea), Wifi module
-
Optional
-
Wall Mount(WM-L000S), Floor Stand(ST-000F / ST-860F)
CERTIFICATION
-
EMC
-
FCC Class "A“
-
ERP / Energy Star
-
Yes / Yes
-
Safety
-
IEC62368, EN62368, GB4943, UL62368
CONNECTIVITY
-
Audio In
-
Yes(1)
-
Audio Out
-
Yes(1)
-
DP In
-
Yes(1), HDCP1.3/2.3
-
HDMI In
-
Yes(4), HDCP2.3
-
HDMI Out
-
Yes(1)
-
RJ45(LAN) In
-
Yes(1)
-
RJ45(LAN) Out
-
Yes(1)
-
RS232C In
-
Yes(1)
-
Touch USB
-
USB2.0 Type A(2)
-
USB In
-
USB Type C(2), USB3.0 Type A(4), USB2.0 Type A(3)
DEDICATED FEATURE - CREATE BOARD
-
Bluetooth
-
Bluetooth 5.0
-
CPU
-
Octa-core A76x4 + A55x4
-
GPU
-
Mali G52MP2
-
LAN
-
Gigabit LAN
-
Memory(RAM)
-
8GB
-
OS ver. (Android)
-
Android 13(EDLA)
-
Storage
-
64GB
-
Wi-Fi
-
802.11 a/b/g/n/ac/ax
DEDICATED FEATURE - TOUCH
-
Accuracy (Typ.)
-
±1mm
-
Available Object Size for Touch
-
Ø2 mm ↑
-
Interface
-
USB2.0
-
Multi Touch Point
-
Max 50 points
-
Operating System Support
-
Windows10/Windows8/Windows7/Android /Linux/Mac OS X/Chrome
-
Protection Glass Thickness
-
3.2mm
-
Protection Glass Transmission
-
88%
-
Response Time ('Paint' app on Windows 10 PC)
-
≤2.5ms
ENVIRONMENT CONDITIONS
-
Operation Humidity
-
10 % to 90 %
-
Operation Temperature
-
0 °C to 40 °C
FEATURE - HARDWARE
-
Auto Brightness Sensor
-
Yes
-
Internal Memory (eMMC)
-
64GB
-
Temperature Sensor
-
Yes
-
Wi-Fi/BT (Built-in)
-
Yes (Slot type)
-
Power Indicator
-
Yes
FEATURE - SOFTWARE
-
Booting Logo Image
-
Yes
-
HDMI-CEC
-
Yes
-
Network Ready
-
Yes (Fast Power On)
-
OS Ver. (webOS)
-
Android13(EDLA)
-
PIP
-
Yes (1) external source
-
Screen Share
-
Yes (CreateBoard Share)
-
Smart Energy Saving
-
Yes (Energy Saving)
-
Wake on LAN
-
Yes
LANGUAGE
-
OSD
-
English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Portugues(Europe), Dutch, Czech, Greek, Arabic, Polski, Hungary, Romania, Thai, Turkiye, Ukraine, Basque, Catalan, Kazakhstan, Indonesia
MECHANICAL SPECIFICATION
-
Bezel Color
-
Black
-
Bezel Width
-
T/R/L/B : 34.3/15.6/15.6/37mm
-
Carton Dimensions (W x H x D)
-
1628 × 208 × 1005mm
-
Handle
-
Yes(2)
-
Monitor Dimensions (W x H x D)
-
1488 × 908 × 87mm
-
Packed Weight
-
48.2kg
-
VESA Standard Mount Interface
-
600x400mm
-
Weight (Head)
-
38.6kg
OPS COMPATIBILITY
-
OPS Power Built-in
-
Yes
-
OPS Type compatible
-
Yes
PANEL
-
Aspect Ratio
-
16:9
-
Back Light Type
-
Direct
-
Brightness
-
400nit (Typ.)
-
Color Depth (Number of Colors)
-
10bit(8bit + FRC)
-
Color Gamut
-
72% (NTSC)
-
Contrast Ratio
-
4,000:1
-
Dynamic CR
-
5,000:1
-
Life time
-
50,000 Hrs (Min.)
-
Native Resolution
-
3840x2160 (UHD)
-
Operation Hours (Hours/Day)
-
16/7
-
Panel Technology
-
IPS
-
Portait / Landscape
-
No / Yes
-
Refresh Rate
-
60Hz
-
Response Time
-
6.5ms(Typ)
-
Screen Size (Inch)
-
65"
-
Surface Treatment (Haze)
-
25%
-
Viewing Angle (H x V)
-
178 x 178
POWER
-
Power Supply
-
AC 100-240V~, 50/60Hz
-
Power Type
-
Built-In Power
POWER CONSUMPTION
-
BTU (British Thermal Unit)
-
665 BTU/Hr(Typ.), 1416 BTU/Hr(Max)
-
DPM
-
0.5W
-
Max.
-
425W
-
Power off
-
0.5W
-
Smart Energy Saving (70%)
-
(TBD)
-
Typ.
-
180W
SOFTWARE COMPATIBILITY
-
Connected Care
-
Yes
SOUND
-
Speaker (Built-in)
-
Yes (18Wx2 + 8Wx2)
