Key Feature
- Inverter
- Design Inovador
- Conectividade Wi-fi
- Controles Avançados
Todas as especificações
CORRENTE (EVAPORADORA)
A/M/B (A)
0.40 / 0.28 / 0.22
VENTILADOR INTERNO
Tipo
Cross Flow Fan
MOTOR DO VENTILADOR DA EVAPORADORA
Saída (Nº)
1
Saída (W)
60
Tipo
BLDC
TROCADOR DE CALOR
Área de Face (m²)
0.28
Líquido (L x A x P) (mm)
998 x 345 x 212
Nº
2
Linhas x Colunas x FPI
2 x 16 x 20 + 1 x 8 x 22
Embalagem (L x A x P) (mm)
1080 x 422 x 281
PESO
Líquido (kg)
12.9
Embalagem (kg)
16.7
CONEXÃO DA TUBULAÇÃO
Gás (mm(pol))
Φ12.7 (1/2)
Líquido (mm(pol))
Φ6.35 (1/4)
REFRIGERANTE
Tipo
R410A
CABO DE CONEXÃO
Cabo de Alimentação e Comunicação (H07RN-F, incluso terra) (mm² x núcleos)
4C x 1.0
FONTE DE ALIMENTAÇÃO
Caso 1
50 Hz 220-240 V~
Caso 2
60 Hz 220 V~
Para acessar mais documentação técnica e downloads, visite o Portal do parceiro B2B da LG.
