Backlight Type
LED (Edge)
Resolution
3,840 x 2,160 (4K UHD)
Brightness (cd/m²)
400
Viewing Angle Degree
178 x 178
Analog
• (PAL/SECAM)
Digital
DVB-T2/C (Varied by countries)
XD Engine
•
Aspect Ratio
• 6 modes (TBD)
(16:9, Original, Full wide, 4:3, Vertical Zoom, All-Direction Zoom)
Audio Output
10W + 10W
Speaker System
2.0 ch
Sound Mode
• 6 modes (Standard, Cinema, Clear Voice III, Sports, Music, Game)
• 6 modes (India, Australia, Newzeland, Srilanka) (Standard, Cinema, Clear Voice III, Cricket, Music, Game)
Clear Voice
• (Clear VoiceⅢ)
Solution Type
Pro:Centric (Smart, V, Direct), Quick Menu 2.0
Data Streaming (IP & RF)
•
RF
• (1 Tuner)
HCAP (SDK)
GEM / Flash / HTML5
Pro:Centric Application
PCA 3.8 (TBD)
Hospitality
Hotel Mode, Lock Mode, Welcome Screen, Insert Image, One Channel Map, External Speaker Out, Instant ON, External Power, V-Lan Tag, RJP Interface, RJP Compatibility, External Clock Compatibility, Clock (World Clock / Alarm), 360 Viewer, Auto Off / Sleep Timer, Smart Energy Saving, Motion Eye Care, Teletext / Auto Teletext (Australia 16:9 only), Conformal Coating
Set Side
HDMI In, USB 2.0 (2), CI Slot
Set Rear
RF In, AV In, Component In (Phone Jack Type), Digital Audio Out (Optical), HDMI / HDCP Input, RS-232C (Control & Service), Headphone Out, Clock Interface (RJ12), External Speaker Out
Vesa
300 x 300
W x H x D / weight (with stand)
1,237 x 774 x 303 / 19.4kg
W x H x D / Weight (without stand)
1,237 x 721 x 36.6 / 16.1kg
W x H x D / weight (Packing)
1,360 x 860 x 190 / 24.1kg
Voltage, Hz
100~240V, 50 / 60 Hz
Max
167
Typical
142
Energy saving (Min / Med / Max)
96 / 69 / 42
Stand-by
0.5W↓
Region
ASIA
