75" 500 nits 120 Hz UHD Signage

Specs

Support

Resource

75" 500 nits 120 Hz UHD Signage

75UH5E-B

75" 500 nits 120 Hz UHD Signage

Print

All Spec

PANEL

  • Screen Size

    75"

  • Penel Technology

    IPS

  • Backlight Type

    Edge

  • Aspect Ratio

    16:09

  • Pixels(HxVx3)

    24,883,200

  • Native Resolution

    3840 x 2160 (UHD)

  • Refresh Rate

    120Hz

  • Brightness

    500nit(typ.)

  • Contrast Ratio

    1,200:1

  • Dynamic CR

    4,000,000:1

  • Colour gamut

    NTSC 72%

  • Viewing Angle(H x V)

    178x178

  • Colour Depth

    10BIT, 1.07 Billion

  • Response Time

    6ms (G to G)

  • Surface Treatment (Haze)

    Haze 3%

  • Life Time(Typ.)

    50,000 Hrs

  • Operation Hours

    24Hrs

  • Orientation

    Portrait & Landscape

CONNECTIVITY

  • Input

    HDM1(3), HDCP2.2, DP1,HDCP2.2, DVI-D1

  • Adudio In

    1

  • USB

    O(2), USB2.0

  • External Control

    RS232C (In/Out), RJ45, IR Receiver, USB

  • Output

    DPOut (1), SST input HDMI 1/2/3/DVI/DP/OPS, Audio Out (1)Off/Fixed/Variable

  • Externel Speaker Out

    Na

  • Audio Out

    1,Off/Fixed/Variable

MECHANICAL SPECIFICATION

  • Bezel Colour

    Black

  • Bezel Width

    On: 15.9mm, Off: 14.9mm

  • Monitor Dimension (W × H × D)

    1,682.4 x 960.3 x 57.9 mm (Without logo and handle)

  • Weight (Head)

    41.5 kg

  • Carton Dimensions (W × H × D)

    1,816 x 1,123 x 228 mm

  • Packed Weight

    49.5kg

  • Handle

    Yes

  • VESA™ Standard Mount Interface

    600 x 400 mm

KEY FEATURE

  • Internal Memory

    8GB(System 4GB + Available 3.6GB)

  • Wi-Fi

    Built-in

  • Sensor

    Temperature Sensor x 1, Auto Brightness Sensor,Current Sensor

  • Local Key Operation

    Yes

  • webOS ver.

    webOS 4.0

  • Embedded CMS

    USB Auto Playback, Local Contents Scheduling, Group Manager

  • Fail over

    Yes

  • Image Customization

    Booting Logo, No Signal

  • Content Sync.

    RS-232C, Local Network

  • Multi-screen

    PIP, PBP(4)

  • Screen Share

    Yes

  • Lock Mode

    Home Dashboard, USB, OSD, IR Operation,Local Key, WiFi, SoftAP, Screen Share

  • Content Rotation

    Yes

  • Gapless Palyback

    Yes

  • Tile Mode

    Yes(Max. 15x15)

  • Setting Data Cloning

    O (RS-232C, Network, USB)

  • Firmware Update by Network

    Yes

  • SNMP

    Ver. 1.4

  • ISM Mode (Image Sticking Minimization)

    Yes

  • Auto Set ID

    Yes

  • Status Mailing

    Yes

  • Control Manager

    Yes

  • 3rd Party Control Compatibility

    Yes

  • Daylight Saving Time

    Yes

  • Beacon

    Yes

  • HDMI-CEC

    Yes

  • SI Server Setting

    Yes

  • Power Mgmt.

    DPM, On/Off Schedule, Holiday Schedule, Power on Status (Standby, PWR, LST), Energy Saving, Smart Energy Saving, PM mode, Wake on LAN, Power on Delay

  • webRTC

    Yes

ENVIRONMENT CONDITIONS

  • Operation Temperature

    0°C to 40°C

  • Operation Humidity

    10 % to 80 %

POWER

  • Power Supply

    100-240V~, 50/60Hz

  • Power Type

    Built-In Power

  • Power Switch

    No

POWER CONSUMPTION

  • Typ

    180

  • Max

    260W

  • BTU (British Thermal Unit)

    614

  • Smart Energy Saving

    126 W

  • DPM

    0.5W

  • Power off

    0.5 W

SOUND

  • Speaker

    Built-in

CERTIFICATION

  • Safety

    CB / NRTL

  • EMC

    FCC Class "A" / CE / KC

  • ErP / Energy Star

    Yes (EU Only) / Yes (Energy Star 8.0)

MEDIA PLAYER COMPATIBILITY

  • OPS type compatible

    Yes

SOFTWARE COMPATIBILITY

  • SuperSign

    CMS, Control (control/control+), White Balance(Sensor Only)

  • Signage 365 Care

    Yes

LANGUAGE

  • OSD

    English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Dannish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek

  • Manual

    English, French, Italian, German, Spanish, Portugues, Hungarian, Greek, Russian, Ukrainian, Polish, Arabic, Indonesian, Korean, Turkish, Czech, Slovak, Taiwanese, Danish, Norwegian, Swedish, Finnish, Uzbekistan

ACCESSORY

  • Basic

    Remote Controller(include battery 2ea), Power Cord, QSG, HDMI Cable, Regulation Book, Phone to RS232C Gender

  • Optional

    OPS Kit (KT-OPSF), Wall Mount (LSW640A/B), Touch Overlay(KT-T75E)

COMPLIANCE INFORMATION

MORE COMPLIANCE INFORMATION

To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
