Screen Size
75" (74.52" Measured Diagonal)
Penel Technology
M+ (WRGB)
Backlight Type
Direct
Resolution
3,840 x 2,160 (UHD)
Aspect Ratio
16:09
Native Resolution
3840 x 2160 (UHD)
Refresh Rate
60Hz
Pixels(HxVx3)
3840 x 2160 , RGBW Stripe arrangement
Brightness
Typ: 2500cd/m2, Min: 2250cd/m2
Contrast Ratio
1200:1 (Typ)
Dynamic CR
500,000:1
Colour gamut
72%(NTSC)
Viewing Angle(H x V)
178x178
Colour Depth
10bit ( Dethering), 1.07 billion colors
Response Time
8ms (G to G BW) typ.
Life Time(Typ.)
50,000 Hrs
Operation Hours
24Hrs
Orientation
Portrait (Clockwise) & Landscape
Surface Treatment (Haze)
AGLR(Haze 3%), QWP
Input
HDMI(2), DP, DVI-D, Audio, USB, SD Card
USB
O(1) USB 3.0
SD Card(SDHC/Full Size)
O(FAT32/NTFS)
Externel Speaker Out
O(1, L/R)
Digital
O(2), HDMI1/2 : HDCP 2.2
Bezel Colour
Black
Bezel Width
11.8 mm Even
Monitor Dimension (W × H × D)
1675.2mm x 953.6mm x 116mm
Weight (Head)
43 kg
Carton Dimensions (W × H × D)
1,816mm x1,106mm x 285mm
Packed Weight
52.2 kg
Handle
Yes(2ea)
VESA™ Standard Mount Interface
600 x 400 mm
Internal Memory
8GB(System 4GB + Available 4GB)
Sensor
Temperature Sensor x 1, Auto Brightness Sensor
webOS ver.
webOS 3.0
Image Customization
No Signal-X (but, support No Signal Text On/Off)
Video Tag
2
Play via URL
X (but, support web browser)
Lock Mode
O (USB, IR, OSD)
Operation Temperature
0 °C to 40°C (w/o Direct Sunlight, Direct Sunlight in Cooling System); 0 °C to 30°C (Direct Sunlight)
Operation Humidity
10 % to 80 %
Power Supply
100-240V~, 50/60Hz
Power Type
Built-In Power
Power Switch
No
Typ
585 W
Max
600 W
Smart Energy Saving
265 W
BTU (British Thermal Unit)
2047
DPM
0.5W(DP, DVI-D, HDMI)
Power off
0.5 W
Speaker
20W(10W x 2) for External Speaker
Safety
CB / NRTL
EMC
FCC Class "A"/CE/KC/VCCI
ErP / Energy Star
Yes / No
OPS type compatible
No
External Media player Attachable
No
OSD
English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Japanese, Russian, Portugues(Europe), Dutch, Czech, Greek, Arabic
Manual
English, French, Italian, German, Spanish, Portugues, Hungarian, Greek, Russian, Dutch, Kazakh, Ukrainian, Polish, Arabic, Indonesian, Korean, Japanese, Turkish, Czech, Taiwanese, Slovak
Content Management Software
SuperSign CMS
Control and Monitoring Software
SuperSign Control/Control+
Basic
Remote Controller (included 2ea batteries), Power Cord, QSG, Mini HDMI Cable (3M x 2ea, for connection between head and signage box), Power Hanness Cable (3M x 2ea, for connection between head and signage box), Regulation Book, Phone to RS232C Gender, Jack Cover, Signage Box Mounting Bracket
Optional
LSW630(wall mount), Stand is not available
