65" 500 nits 60 Hz UHD Signage
UKEU
Product Information Sheet

65" 500 nits 60 Hz UHD Signage

UKEU
Product Information Sheet

65" 500 nits 60 Hz UHD Signage

65UH5E-B
LG 65" 500 nits 60 Hz UHD Signage, 65UH5E-B
LG 65" 500 nits 60 Hz UHD Signage, 65UH5E-B
LG 65" 500 nits 60 Hz UHD Signage, 65UH5E-B
LG 65" 500 nits 60 Hz UHD Signage, 65UH5E-B
LG 65" 500 nits 60 Hz UHD Signage, 65UH5E-B
LG 65" 500 nits 60 Hz UHD Signage, 65UH5E-B
LG 65" 500 nits 60 Hz UHD Signage, 65UH5E-B
LG 65" 500 nits 60 Hz UHD Signage, 65UH5E-B
LG 65" 500 nits 60 Hz UHD Signage, 65UH5E-B
LG 65" 500 nits 60 Hz UHD Signage, 65UH5E-B
LG 65" 500 nits 60 Hz UHD Signage, 65UH5E-B
LG 65" 500 nits 60 Hz UHD Signage, 65UH5E-B
LG 65" 500 nits 60 Hz UHD Signage, 65UH5E-B
LG 65" 500 nits 60 Hz UHD Signage, 65UH5E-B

Key Features

  • Brightness(Typ.) : 500 cd/m²
  • Bezel : 12.1 mm (T), 12.6 mm (R/L), 15.7 mm (B)
  • Depth : 40.1 mm
  • Interface : HDMI(3)/DP/DVI-D/USB 2.0(2)/ RS232C/ RJ45/ Audio/ IR/ External Speaker Out
  • Haze 28%
More
Print

All Spec

PANEL

  • Screen Size

    65"

  • Penel Technology

    IPS

  • Backlight Type

    Edge

  • Aspect Ratio

    16:09

  • Native Resolution

    3,840 x 2,160 (UHD, RGB)

  • Pixels(HxVx3)

    24,883,200

  • Refresh Rate

    60Hz

  • Brightness

    500nit(typ.)

  • Contrast Ratio

    1,100:1

  • Colour gamut

    68%

  • Viewing Angle(H x V)

    178x178

  • Colour Depth

    1.07 Billion

  • Response Time

    8ms (G to G)

  • Surface Treatment (Haze)

    Haze 28%

  • Life Time(Typ.)

    50,000 Hrs

  • Operation Hours

    24Hrs

  • Orientation

    Portrait & Landscape

ENVIRONMENT CONDITIONS

  • Operation Temperature

    0°C to 40°C

  • Operation Humidity

    10 % to 80 %

POWER

  • Power Supply

    100-240V~, 50/60Hz

  • Power Type

    Built-In Power

  • Power Switch

    No

POWER CONSUMPTION

  • Typ

    140

  • Max

    200

  • BTU (British Thermal Unit)

    478

  • Smart Energy Saving

    98 W

  • DPM

    0.5W

  • Power off

    0.5 W

ACCESSORY

  • Basic

    Remote Controller(include battery 2ea), Power Cord, QSG, HDMI Cable, Regulation Book, Phone to RS232C Gender

  • Optional

    Speaker(SP-5200), Stand(ST-651T),Wall bracket(LSW350B), VESA Adapter(AM-B330S), OPS Kit(KT-OPSF)

MEDIA PLAYER COMPATIBILITY

  • OPS type compatible

    Yes

SOFTWARE COMPATIBILITY

  • SuperSign

    CMS, Control (control/control+), White Balance(Sensor Only)

  • Signage 365 Care

    Yes

MECHANICAL SPECIFICATION

  • Bezel Colour

    Black

  • Bezel Width

    12.1 mm (T), 12.6 mm (R/L), 15.7 mm (B)

  • Monitor Dimension (W × H × D)

    1,458.6 x 848.9 x 40.1 mm

  • Weight (Head)

    26 kg

  • Weight (Head+Stand)

    27.4 kg

  • Monitor with Optional Stand Dimensions (W x H x D)

    1458.6mm x 915.8 mm x 313.9mm

  • Carton Dimensions (W × H × D)

    1,561 x 971 x 190 mm

  • Weight (Head +Stand & Speaker)

    28.1 kg

  • Packed Weight

    32.5 kg

  • Handle

    No

  • VESA™ Standard Mount Interface

    300 x 300 mm

SOUND

  • Speaker

    No

CERTIFICATION

  • Safety

    CB / NRTL

  • EMC

    FCC Class "A" / CE / KC

  • ErP / Energy Star

    Yes (EU Only) / Yes (Energy Star 8.0)

  • ePEAT(US only)

    NA

CONNECTIVITY

  • Input

    HDM1(3), HDCP2.2, DP1,HDCP2.2, DVI-D1

  • Adudio In

    1

  • Output

    DPOut (1), SST input HDMI 1/2/3/DVI/DP/OPS, Audio Out (1)Off/Fixed/Variable

  • External Control

    RS232C IN 1, RJ45(LAN)1, IR in1

  • Externel Speaker Out

    O(1, L/R), 6Ω

  • USB

    O(2), USB2.0

KEY FEATURE

  • Internal Memory

    8GB(System 4GB + Available 3.6GB)

  • Wi-Fi

    Built-in

  • Sensor

    Temperature Sensor x 1, Auto Brightness Sensor,Current Sensor

  • Local Key Operation

    Yes

  • webOS ver.

    webOS 4.0

  • Embedded CMS

    USB Auto Playback, Local Contents Scheduling, Group Manager

  • Image Customization

    Booting Logo, No Signal

  • Content Sync.

    RS-232C, Local Network

  • Multi-screen

    PIP, PBP(4)

  • Screen Share

    Yes

  • Video Tag

    2

  • Play via URL

    Yes

  • OSD Rotation

    Yes

  • Lock Mode

    O(Home Dashboar, USB, OSD, IR Operation, Local Key, WiFi, SoftAP, Screen Share)

  • Content Rotation

    Yes

  • Gapless Palyback

    Yes

  • Tile Mode

    Yes(Max. 15x15)

  • Setting Data Cloning

    O (RS-232C, Network, USB)

  • Firmware Update by Network

    Yes

  • SNMP

    Ver. 1.4

  • ISM Mode (Image Sticking Minimization)

    Yes

  • Auto Set ID

    Yes

  • Status Mailing

    Yes

  • Control Manager

    Yes

  • 3rd Party Control Compatibility

    Yes

  • Power Mgmt.

    DPM, On/Off Schedule, Holiday Schedule, Power on Status (Standby, PWR, LST), Energy Saving, Smart Energy Saving, PM mode, Wake on LAN, Power on Delay

  • Beacon

    Yes

  • Fail over

    Yes

  • Daylight Saving Time

    Yes

  • HDMI-CEC

    Yes

  • SI Server Setting

    Yes

  • webRTC

    Yes

LANGUAGE

  • OSD

    English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Dannish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek

  • Manual

    English, French, Italian, German, Spanish, Portugues, Hungarian, Greek, Russian, Dutch, Kazakh, Ukrainian, Polish, Arabic, Indonesian, Korean, Japanese, Turkish, Czech, Taiwanese, Slovak

COMPLIANCE INFORMATION

MORE COMPLIANCE INFORMATION
The safety information for accessories is included with the safety information for the product and is not provided separately.

To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
