Screen Size
75"
Penel Technology
IPS
Backlight Type
Edge
Aspect Ratio
16:09
Pixels(HxVx3)
24,883,200
Native Resolution
3840 x 2160 (UHD)
Refresh Rate
120Hz
Brightness
500nit(typ.)
Contrast Ratio
1,200:1
Dynamic CR
4,000,000:1
Colour gamut
NTSC 72%
Viewing Angle(H x V)
178x178
Colour Depth
10BIT, 1.07 Billion
Response Time
6ms (G to G)
Surface Treatment (Haze)
Haze 3%
Life Time(Typ.)
50,000 Hrs
Operation Hours
24Hrs
Orientation
Portrait & Landscape
Input
HDM1(3), HDCP2.2, DP1,HDCP2.2, DVI-D1
Adudio In
1
USB
O(2), USB2.0
External Control
RS232C (In/Out), RJ45, IR Receiver, USB
Output
DPOut (1), SST input HDMI 1/2/3/DVI/DP/OPS, Audio Out (1)Off/Fixed/Variable
Externel Speaker Out
Na
Audio Out
1,Off/Fixed/Variable
Bezel Colour
Black
Bezel Width
On: 15.9mm, Off: 14.9mm
Monitor Dimension (W × H × D)
1,682.4 x 960.3 x 57.9 mm (Without logo and handle)
Weight (Head)
41.5 kg
Carton Dimensions (W × H × D)
1,816 x 1,123 x 228 mm
Packed Weight
49.5kg
Handle
Yes
VESA™ Standard Mount Interface
600 x 400 mm
Internal Memory
8GB(System 4GB + Available 3.6GB)
Wi-Fi
Built-in
Sensor
Temperature Sensor x 1, Auto Brightness Sensor,Current Sensor
Local Key Operation
Yes
webOS ver.
webOS 4.0
Embedded CMS
USB Auto Playback, Local Contents Scheduling, Group Manager
Fail over
Yes
Image Customization
Booting Logo, No Signal
Content Sync.
RS-232C, Local Network
Multi-screen
PIP, PBP(4)
Screen Share
Yes
Lock Mode
Home Dashboard, USB, OSD, IR Operation,Local Key, WiFi, SoftAP, Screen Share
Content Rotation
Yes
Gapless Palyback
Yes
Tile Mode
Yes(Max. 15x15)
Setting Data Cloning
O (RS-232C, Network, USB)
Firmware Update by Network
Yes
SNMP
Ver. 1.4
ISM Mode (Image Sticking Minimization)
Yes
Auto Set ID
Yes
Status Mailing
Yes
Control Manager
Yes
3rd Party Control Compatibility
Yes
Daylight Saving Time
Yes
Beacon
Yes
HDMI-CEC
Yes
SI Server Setting
Yes
Power Mgmt.
DPM, On/Off Schedule, Holiday Schedule, Power on Status (Standby, PWR, LST), Energy Saving, Smart Energy Saving, PM mode, Wake on LAN, Power on Delay
webRTC
Yes
Operation Temperature
0°C to 40°C
Operation Humidity
10 % to 80 %
Power Supply
100-240V~, 50/60Hz
Power Type
Built-In Power
Power Switch
No
Typ
180
Max
260W
BTU (British Thermal Unit)
614
Smart Energy Saving
126 W
DPM
0.5W
Power off
0.5 W
Speaker
Built-in
Safety
CB / NRTL
EMC
FCC Class "A" / CE / KC
ErP / Energy Star
Yes (EU Only) / Yes (Energy Star 8.0)
OPS type compatible
Yes
SuperSign
CMS, Control (control/control+), White Balance(Sensor Only)
Signage 365 Care
Yes
OSD
English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Dannish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek
Manual
English, French, Italian, German, Spanish, Portugues, Hungarian, Greek, Russian, Ukrainian, Polish, Arabic, Indonesian, Korean, Turkish, Czech, Slovak, Taiwanese, Danish, Norwegian, Swedish, Finnish, Uzbekistan
Basic
Remote Controller(include battery 2ea), Power Cord, QSG, HDMI Cable, Regulation Book, Phone to RS232C Gender
Optional
OPS Kit (KT-OPSF), Wall Mount (LSW640A/B), Touch Overlay(KT-T75E)
