Screen Size
86"
Penel Technology
IPS
Backlight Type
Edge
Aspect Ratio
16:09
Native Resolution
3840 x 2160 (UHD)
Pixels(HxVx3)
24,883,200
Refresh Rate
120Hz
Colour gamut
NTSC 72%
Brightness
500nit(typ.)
Contrast Ratio
1,200:1
Dynamic CR
4,000,000:1
Viewing Angle(H x V)
178x178
Colour Depth
10BIT, 1.07 Billion
Response Time
8ms (G to G)
Surface Treatment (Haze)
Haze 3%
Life Time(Typ.)
50,000 Hrs
Orientation
Portrait & Landscape
Operation Hours
24Hrs
Speaker
Built-in
Input
HDM1(3), HDCP2.2, DP1,HDCP2.2, DVI-D1
Adudio In
1
External Control
RS232C Out o(1), 4 pin phone-jack
Output
DPOut O(1, SST input HDMI 1/2/3/DVI/DP/OPS, Audio Out O(1,Off/Fixed/Variable)
USB
O(2), USB2.0
Bezel Colour
Black
Bezel Width
On: 15.6mm, Off: 14.3mm
Monitor Dimension (W × H × D)
1,926.2 x 1,097.2 x 60.6 mm (without Handle)
Weight (Head)
49kg
Carton Dimensions (W × H × D)
2,073 x 1,260 x 292 mm
Packed Weight
61.1kg
Handle
Yes
VESA™ Standard Mount Interface
600 x 400 mm
Internal Memory
8GB(System 4GB + Available 3.6GB)
Wi-Fi
Built-in
Sensor
Temperature Sensor x 1, Auto Brightness Sensor,Current Sensor
Local Key Operation
Yes
webOS ver.
webOS 4.0
Embedded CMS
USB Auto Playback, Local Contents Scheduling, Group Manager
Fail over
Yes
Image Customization
Booting Logo, No Signal
Content Sync.
RS-232C, Local Network
Multi-screen
PIP, PBP(4)
Screen Share
Yes
Video Tag
2
Play via URL
Yes
OSD Rotation
Yes
Lock Mode
O(Home Dashboar, USB, OSD, IR Operation, Local Key, WiFi, SoftAP, Screen Share)
Content Rotation
Yes
Gapless Palyback
Yes
Tile Mode
Yes(Max. 15x15)
Setting Data Cloning
O (RS-232C, Network, USB)
Firmware Update by Network
Yes
SNMP
Ver. 1.4
ISM Mode (Image Sticking Minimization)
Yes
Auto Set ID
Yes
Status Mailing
Yes
3rd Party Control Compatibility
Yes
Control Manager
Yes
Power Mgmt.
DPM, On/Off Schedule, Holiday Schedule, Power on Status (Standby, PWR, LST), Energy Saving, Smart Energy Saving, PM mode, Wake on LAN, Power on Delay
Daylight Saving Time
Yes
Beacon
Yes
HDMI-CEC
Yes
SI Server Setting
Yes
webRTC
Yes
Operation Temperature
0°C to 40°C
Operation Humidity
10% to 80%
Power Supply
100-240V~, 50/60Hz
Power Type
Built-In Power
Power Switch
No
Typ
215
Max
280
BTU (British Thermal Unit)
734
Smart Energy Saving
151W
DPM
0.5W
Power off
0.5 W
Safety
CB / NRTL
EMC
FCC Class "A"/CE/KC
ErP / Energy Star
Yes (EU Only) / N/A
OPS type compatible
Yes
SuperSign
CMS, Control (control/control+), White Balance(Sensor Only)
Signage 365 Care
Yes
OSD
English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Dannish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek
Manual
English, French, Italian, German, Spanish, Portugues, Hungarian, Greek, Russian, Dutch, Kazakh, Ukrainian, Polish, Arabic, Indonesian, Korean, Japanese, Turkish, Czech, Taiwanese, Slovak
Basic
Remote Controller, Power Cord, QSG, DP Cable (1.8M), Regulation Book, Phone to RS232C Gender
Optional
OPS Kit (KT-OPSF), Wall Mount (LSW640A/B), Touch Overlay(KT-T75E)
