Backlight Type
Direct LED
Screen Size
86" (85.6" measured diagonal)
Panel Technology
IPS
Aspect Ratio
58:09:00
Native Resolution
3840 x 600 (UHD)
Pixels(H x V x 3)
6,912,000
Brightness
Typ: 500cd/m2, Min : 400cd/m2
Contrast Ratio
1,100:1(Typ)
Dynamic CR
500,000:1 (Typ)
Color Gamut
72%
Viewing Angle(H x V)
178x178
Color Depth
10bit(D)
Response Time
8ms(G to G BW) typ.
Surface Treatment
AGP (10% Haze)
Life time
50,000 Hrs
Operation Hours
24Hrs
Orientation
Landscape, Portrait
Refresh Rate
60Hz
Max Input Resolution
3840 x 2160@60Hz (HDMI1,2) 3840 x 2160@30Hz (HDMI3, DisplayPort), 3840 x 600@60Hz (OPS), 1920 x 1080@60Hz(DVI)
Recommended Resolution
3840 x 600@60Hz (HDMI1~3, DisplyPort, OPS), 1920 x 300@60Hz(DVI)
H-Scanning Frequency
28.1 ~ 83kHz
V-Scanning Frequency
50 ~ 60Hz
Pixel Frequency
148.5MHz
Sync Compatability
Digital
Video Input
HDMI1, HDMI2, HDMI3, DVI-D, Display Port, OPS
Picture mode
Vivid, Standard, APS, Cinema, Sports, Game, Expert1/2
Color temperature
Warm50 ~ Cool50
Input - Digital (With HDCP) - HDMI
Yes (3), HDMI1/2 : HDCP 2.2, HDMI3 : HDCP 1.4
Input - Digital (With HDCP) - DP
Yes (1), HDCP 1.3
Input - Digital (With HDCP) - OPS
Yes (1)
Input - Digital (With HDCP) - DVI-D
Yes (1)
Analog Audio
Yes (1)
External Control - RS232C
Yes (1)
External Control - RJ45
Yes (1)
External Control - IR+B Receiver
Yes (1)
USB
Yes (USB2.0 x1 / 3.0 x 1)
SD Card
Yes (FAT32 / NTFS)
Output - Digital (With HDCP)
Yes (DP x1) (HDCP output only DP input)
Analog Audio (Line Out)
Yes (1)
External Control - RS232C/br
Yes (1)
External Control - RJ45/br
Yes (1)
Bezel Color
Black
Bezel Width
4.4mm(L/R), 5.9mm(U/D)
Monitor Dimension(W x H x D)
2158.3x348.5x81.7
Weight(Head)
20.5Kg
Carton Dimensions(W x H x D)
2290x599x228
Packed Weight
38.2Kg
Handle
Yes
VESATM Standard Mount Interface
600 x 200
Temperature Sensor
Yes
Auto Brightness sensor
Yes
Tile Mode
Yes (5x5)
Natural Mode @Tile Mode
Yes
Source Selection
HDMI1, HDMI2, HDMI3/DVI-D/OPS, DP
Brightness/Contrast/Backlight
Yes
Language (OSD)
English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Japanese, Russian, Portugues(Europe), Dutch, Czech, Greek, Arabic
Language (USB Playback)
English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Japanese, Russian, Portugues(Europe), Dutch, Czech, Greek, Arabic
Language (Manual)
English, French, Italian, German, Spanish, Portugues, Hungarian, Greek, Russian, Dutch, Kazakh, Ukrainian, Polish, Arabic, Indonesian, Korean, Japanese, Turkish, Czech, Taiwanese, Slovak
Language (ESG)
English, French, Italian, German, Spanish, Portugues, Greek, Polish, Czech, Slovak
ISM Method
ALL
Advanced
Dynamic Contrast, Dynamic Color, Clear White, Skin Color, Noise Reduction, Digital Noise Reduction, Gamma, Black Level
Time
Clock, On/Off Time, Power on Delay, Auto Off,Automatic Standby
Information
Model/Type, Software Version, Serial Number, IP Address, Homepage
Input Label
Yes(PC/DTV)
Auto Power/Source Memory
Yes
Key Lock
Yes
DPM Select
Yes
Energy Saving
Yes(Minimum, Medium, Maxium)
Smart Energy Saving
Yes
File Play with USB/SD/Internal Memory
Yes
PIP/PBP
2/3/4PBP
Internal Memory
8GB(System 4GB + Available 4GB)
Wi-Fi
Dongle ready(Support Beacon function)
4K Up Scaling
Yes
Beacon
On/Off
PM mode
Power Off, Sustain Aspect Ratio, Screen Off, Screen Off Always
Lock mode
USB, OSD, IR Operation, Local Key Operation
Media share
SoftAP
Operation Temperature
0 °C to 40 °C
Operation Humidity
10 % to 80 %
Power Supply
100-240V~, 50/60Hz
Power Type
Built-In Power
Typ./Max
180W/220W
Smart Enegy Saving
30% of typical
DPM
HDMI1,2,3,DVI-D,OPS:30W, DP:1W
Power off
0.5W
Safety
UL / cUL / CB / TUV / KC
EMC
FCC Class "A" / CE / KC
OPS PC compatible (optional)
Yes
SuperSign CMS
Yes
SuperSign Link
Yes
SuperSign WB
Yes
Accessory
Remote Controller(including battery 2ea), Power Cord, DP(2.6M), RS-232C Cable(3M) Owner's Manual(Website upload)
Optional Accessory
AN-WF500(WiFi USB Dongle), KT-OPSA(OPS KIT), ** Stand is not available
