R32 Split 5/7/9 kW Hydro Box, 1Ø, 5kW
UKEU
Product Information Sheet
Contact Us

R32 Split 5/7/9 kW Hydro Box, 1Ø, 5kW

UKEU
Product Information Sheet

Share this content.

You can share the items you like with your friends.

R32 Split 5/7/9 kW Hydro Box, 1Ø, 5kW

HN091MR NK5 + HU051MR U44
Front view of R32 Split 5/7/9 kW Hydro Box, 1Ø, 5kW HN091MR NK5 + HU051MR U44
Front view of R32 Split 5/7/9 kW Hydro Box, 1Ø, 5kW HN091MR NK5 + HU051MR U44

Key Features

  • Suitable for both new build and renovation projects.
  • Light weight and compact size / Demonstrates a lower noise level
  • Flexible refrigerant piping design
  • ErP energy label class LWT A+++/A++ (35°C/55°C)
  • High leaving water temperature up to 65°C and wide operating range down to -25°C ambient temperature
  • Connectivity with Wi-Fi control (ThinQ), smart grid and PV/ESS
More

  1. No risk of pipe freezing

    Refrigerant pipe robust to cold ensures no potential risk of pipe freezing even during prolonged blackouts.

  2. Remarkable performance in cold

    Wide operation range ensures remarkable heating performance even in an extremely cold weather.

  3. Low noise level

    Noise reduction technology provides quieter and more comfortable experience, increasing installation flexibility in urban areas.

Key Feature

  • Suitable for both new build and renovation projects.
  • Light weight and compact size / Demonstrates a lower noise level
  • Flexible refrigerant piping design
  • ErP energy label class LWT A+++/A++ (35°C/55°C)
  • High leaving water temperature up to 65°C and wide operating range down to -25°C ambient temperature
  • Connectivity with Wi-Fi control (ThinQ), smart grid and PV/ESS
Print

All Spec

SEASONAL EFFICIENCY DATA (HEATING)

  • Seasonal space heating eff. class (35℃ / 55℃)

    A+++/A++

  • Seasonal space heating efficiency (ηS) (35℃ / 55℃)

    183 / 126

  • SCOP (35℃ / 55℃)

    4.65 / 3.23

NOMINAL CAPACITY AND COP (A+7/W+35)

  • Heating capacity (kW)

    5.50

  • COP

    4.90

NOMINAL CAPACITY AND COP (A+2/W+35)

  • Heating capacity (kW)

    3.30

  • COP

    3.52

NOMINAL CAPACITY AND COP (A+7/W+55)

  • Heating capacity (kW)

    5.50

  • COP

    2.70

NOMINAL CAPACITY AND EER (A+35/W+18)

  • Cooling capacity (kW)

    5.50

  • EER

    4.60

NOMINAL CAPACITY AND EER (A+35/W+7)

  • Cooling capacity (kW)

    5.50

  • EER

    2.80

OPERATION RANGE (OUTDOOR AIR TEMPERATURE)

  • Heating & DHW (Min. ~ Max.) (℃)

    -25 ~ 35

  • Cooling (Min. ~ Max.) (℃)

    5 ~ 48

OPERATION RANGE (LEAVING WATER TEMPERATURE)

  • Heating (Min. ~ Max.) (℃)

    15 ~ 65

  • Cooling (Min. ~ Max.) (℃)

    5 ~ 27

  • DHW (Min. ~ Max.) (℃)

    15 ~ 80

REFRIGERANT

  • Type

    R32

  • GWP

    675

  • Precharged amount (g)

    1,500

PIPING CONNECTIONS (REF./OUTDOOR UNIT)

  • Gas (mm (inch))

    Ø 15.88 (5/8)

  • Liquid (mm (inch))

    Ø 9.52 (3/8)

  • Length standard / Max. (m)

    5 / 50

  • Level difference Max. (m)

    30

  • Max. length without additional charge (m)

    10

  • Mass of additional ref. charge (g/m)

    40

PIPING CONNECTIONS (WATER/INDOOR UNIT)

  • Inlet diameter for space heating (inch)

    Male PT 1"

  • Outlet diameter for space heating (inch)

    Male PT 1"

SOUND POWER LEVEL (OUTDOOR UNIT)

  • Rated / low noise mode (dB(A))

    60 / 58

SOUND POWER LEVEL (INDOOR UNIT)

  • Rated (dB(A))

    44

SOUND PRESSURE LEVEL AT 5M (OUTDOOR UNIT, CONVERT USING SWL)

  • Rated / low noise mode (dB(A))

    38 / 36

SOUND PRESSURE LEVEL AT 1M (INDOOR UNIT, CONVERT USING SWL)

  • Rated (dB(A))

    36

DIMENSIONS

  • Outdoor unit (W × H × D) (mm)

    950 × 834 × 330

  • Indoor unit (W × H × D) (mm)

    490 × 850 × 315

WEIGHT

  • Outdoor unit (Empty) (kg)

    60.0

  • Indoor unit (Empty) (kg)

    38.1

EXTERIOR

  • Outdoor unit (Color / RAL code)

    Warm gray / RAL 7044

  • Indoor unit (Color / RAL code)

    Noble white / RAL 9016

POWER SUPPLY

  • Voltage, phase, frequency (V, Ø, Hz)

    220-240, 1, 50

COMPLIANCE INFORMATION

MORE COMPLIANCE INFORMATION
The safety information for accessories is included with the safety information for the product and is not provided separately.
To learn more about how this product handles data and your rights as a user, please visit ″Data Coverage & Specifications″ at LG Privacy

To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
