Key Features
The independent vane operation feature utilises separate motors, making it possible to control all four vanes independently.
It can be monitored and controlled via your mobile device to conserve energy and ensure better air quality.
Safe Plus Insulation is an antimicrobial treatment that is applied to LG MULTI V indoor unit’s internal insulation components to create resistance to bacterial growth, and provides cleaner and fresher airflow for the customer.
#1
50 Hz 220-240 V~
#2
60 Hz 220 V~
Air Flow Rate(Cooling,(SH)/H/M/L) (m³/min)
- / 11.1 / 10.3 / 9.1
O.D / I.D (mm(inch))
25(1)
Cooling((SH)/H/M/L) (dB(A))
- / 34 / 32 / 29
Heating((SH)/H/M/L) (dB(A))
- / 34 / 32 / 29
Cooling((SH)/H/M/L) (dB(A))
- / 44 / 42 / 40
Heating((SH)/H/M/L) (dB(A))
- / 44 / 42 / 40
Model Name
PT-USC
Type
Ceiling Cassette
Net(W x H x D) (mm)
830 x 225 x 600
Net (kg)
18.1
Liquid (mm(inch))
Φ6.35 (1/4)
Gas (mm(inch))
Φ12.7 (1/2)
Nominal (kW)
3.60
Nominal (kW)
4.00
