* The 2 video tags may expand to 4 video tags in the 3Q of 2019.
* The availability of "Signage 365 Care" service can differ by region,
so please contact the LG sales representative in your region for further details.
Input
HDMI (2), DP, USB 2.0 (2)
Output
HDMI, DP(Daisy chain only)
External Control
RS232C in/out, RJ45 in, IR in
Player Dimension (W x H x D)
258 × 36.5 × 186 mm
Weight
1.4 kg
Carton Dimensions (W × H × D)
314 x 124 x 359 mm
Packed Weight
2.26 kg
Internal Memory 8GB (System 4GB, Available 4GB), Wi-Fi Built-in (ac combo), Thermal Sensor, Power Indicator, Local Key Operation
webOS ver.
webOS 4.0
Embedded CMS
USB Auto Playback, Local Contents Scheduling, Group Manager
Fail over
Yes
Image Customization
No Signal
Content Sync.
RS-232C, Local Network
Multi-screen
PIP/PBP(4)
Screen Share
Yes
Video Tag
Yes (2)
Play via URL
Yes
OSD Rotation
Yes
Lock mode
Yes (Home Dashboard, USB, OSD, IR Operation, Local Key, WiFi, Screen Share)
Content Rotation
Yes
Gapless Playback
Yes
Tile Mode Setting
Yes (Max. 15x15)
Setting Data Cloning
Yes (Network, USB)
Firmware Update by Network
Yes
SNMP(ver.2)
Yes
ISM Modebr(Image Sticking Minimization)
Yes
Status Mailing
Yes
Power Mgmt.
DPM, On/Off Schedule, Holiday Schedule, Power on Status, Smart Energy Saving, Wake on LAN, Power on Delay
Control Manager
Yes
Daylight Saving Time
Yes
Beacon
Yes
HDMI-CEC
Yes *Compatibility may differ by equipment.
SI Server Setting
Yes
webRTC
Yes
Operation Temperature
0°C to 40°C
Operation Humidity
10% to 80%
Power Supply
100-240V~, 50/60Hz
Power Type
Built-In Power
Typ./Max
16 W / 22 W
Safety
CB
EMC
CE Class A
Content Management Software
SuperSign CMS
Control and Monitoring Software
SuperSign Control/Control+
Basic
Remote Controller, Power Cord, QSG, HDMI Cable, Regulation Book, Phone to RS232C Gender
