The content with the 90° Corner Option is shown without any interruptions even when installed on a corner.
An LG service man is monitoring the status of the LED screen through the LG webOS controller and software solutions.
* The availability of the 'LG ConnectedCare' service differs by region, and it needs to be purchased separately. So please contact the LG sales representative in your region for more details.
* The items that can be monitored by LG ConnectedCare: Main Board (Temp., Signal Status, FPGA Ver, Ethernet Connection Status), Receiving Card (Temp., LED Power)
Both walls of the indoor hallway are curved, and LEDs are installed along the entire wall.
* Applied to the LSCB15-CKF, LSCB18-CKF, and LSCB25-CKF models only. The LSCB12-CKF supports curvatures of up to 1,720 mm.
Pixel Configuration
3 in 1
Pixel Pitch (mm)
1.250
Module Resolution (WxH)
240 × 135
Module Dimensions(WxH,mm)
300 × 168.75
Weight per Module (kg)
0.37 (-RK,-CK)/ 0.67 (-CKF)
No. of Modules per Cabinet (WxH)
2x2 (-RK)/ 1x2 (-CK,-CKF)
Cabinet Resolution (WxH)
480x270 (-RK)/ 240x270 (-CK, -CKF)
Cabinet Dimensions (W x H x D, mm)
600x337.5x34 (-RK)/300x337.5x29.7 (-CK)/300x337.5x35.6 (-CKF, Cabinet Mounting Depth)
Cabinet Surface Area (㎡)
0.203 (-RK)/ 0.101 (-CK, -CKF)
Weight per Cabinet (kg/unit)
5.3 (-RK)/ 4.0 (-CK)/3.5 (-CKF, Weight Changes for Different Curves)
Weight per Square Meter (kg/㎡)
26.2 (-RK)/ 39.0 (-CK)/ 34.6 (-CKF)
Physical Pixel Density (pixels/㎡)
640,000
Flatness of Cabinet (mm)
± 0.1 mm
Cabinet material
Die-casting Aluminum (-RK)/Aluminum Machine (-CK, CKF)
Service access
Front
Max Brightness (After Calibration, nit)
800
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
160
Brightness Uniformity(%)
97%
Color Uniformity
± 0.003 Cx,Cy
Contrast Ratio
5,000 : 1
Processing Depth (bit)
14 (HDR10, HDR10 Pro)
Color Temperature
3,200-9,300 (K)
Power Consumption (W/Cabinet, Max.)
150 (-RK)/ 75 (-CK, -CKF)
Power Consumption (W/Cabinet, Avg.)
50 (-RK)/ 25 (-CK, CKF)
Power Consumption (W/㎡, Max.)
740
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
3,840
Operating Temperature(℃)
-10° to +45°
Operating Humidity
0 - 80 % RH
IP rating Front
IP30
IP rating Rear
IP30
LED Lifetime (Half brightness)
100,000
Controller
CVCA, LCIN006, LCIN008 (4K)
90 degree corner cut
Yes
