If you add 90°corner option, the LSCB series fits naturally into the space and delivers smooth content to customers.
The content with the 90° Corner Option is shown without any interruptions even when installed on a corner.
When connected with LG's CVCA system controller, the LSCB series is compatible with LG software solutions including SuperSignCMS, LED Assistant, and ConnectedCare, which help customers operate their own business deftly.
An LG service man is monitoring the status of the LED screen through the LG webOS controller and software solutions.
*The availability of the 'LG ConnectedCare' service differs by region, and it needs to be purchased separately. So please contact the LG sales representative in your region for more details.
*The items that can be monitored by LG ConnectedCare: Main Board (Temp., Signal Status, FPGA Ver, Ethernet Connection Status), Receiving Card (Temp., LED Power)
The LSCB-CKF, a specially-designed flexible curved LED display, supports true concave and convex curvatures up to 383 mm*. This greatly enhances the design’s flexibility, which allows users to freely create the curved screen as they want.
Both walls of the indoor hallway are curved, and LEDs are installed along the entire wall.
*Applied to the LSCB15-CKF, LSCB18-CKF, and LSCB25-CKF models only. The LSCB12-CKF supports curvatures of up to 1,720 mm.
The LSCB series is designed to support redundancy of signal and power, providing users with comfort. With an optional embedded backup power supply unit and signal redundancy, customers may experience the continuous operation of the screen without power failure, while the dual controllers can reduce screen failures with bi-directional signal input.
In the case of “LG Conventional LED Signage” even more than the error is blacked out, but in the case of “LG LSCB Series” only the error is blacked out and displayed.
*The “Conventional” shown above refers to LED displays which do not support the power/signal redundancy mode.
**The power redundancy model is optional.
***In the case of power redundancy, additional costs can be added.
Model name
LSCB012-RKR
Pixel Configuration
Single SMD
Pixel Pitch (mm)
1.25
Module Resolution (WxH)
240x135
Module Dimensions(WxH,mm)
300x168.75
Weight per Module (kg)
0.37
No. of Modules per Cabinet (WxH)
2x2
Cabinet Resolution (WxH)
480x270
Cabinet Dimensions (W x H x D, mm)
600x337.5x34
Cabinet Surface Area (㎡)
0.203
Weight per Cabinet (kg/unit)
5.3
Weight per Square Meter (kg/㎡)
26.2
Physical Pixel Density (pixels/㎡)
640,000
Flatness of Cabinet (mm)
±0.1
Cabinet material
Die-casting Aluminum
Service access
Front
Max Brightness (After Calibration, nit)
800
Color Temperature (K)
3,200~9,300
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
160
Brightness Uniformity(%)
97%
Color Uniformity
±0.003Cx,Cy
Contrast Ratio
5,000:1
Processing Depth (bit)
14 (HDR10, HDR10 Pro)
Power Consumption (W/Cabinet, Max.)
150
Power Consumption (W/Cabinet, Avg.)
50
Power Consumption (W/㎡, Max.)
740
Heat Dissipation (BTU/h/Cabinet, Max.)
512
Heat Dissipation (BTU/h/Cabinet, Avg.)
171
Heat Dissipation (BTU/h/㎡, Max.)
2,528
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
3,840
LED Lifetime (Half brightness)
100,000
Operating Temperature(℃)
-10℃ to +45℃
Operating Humidity
0~80%RH
IP rating Front
IP30
IP rating Rear
IP30
Certification
CE, FCC, ETL, EMC Class-B, Fire Protection
Environment
RoHS, REACH
Controller
CVCA
90 degree corner cut
Yes
