P2.0 1,000 nits LG LED Curve Series for Indoor
LAP020EL6B
Orders for the Scottish Islands and remote areas will be delivered by 3PL. The 3PL will contact you to arrange a suitable delivery date.
Shipping options may vary by region.
Further information regarding delivery can be found in our Delivery Terms and Conditions.
Are you sure you want to remove the coupon?
Pitch Name
P2.0
Pixel Configuration
3 in 1 SMD
Pixel Pitch(mm)
2.00
Module Resolution (WxH)
120x90
Module Dimensions(WxH,mm)
240x180
Weight per Module (kg)
0.36
No. of Modules per Unit Case (WxH)
2x3
Unit Case Resolution (WxH)
240x270
Unit Case Dimensions (W x H x D, mm)
480x540x40
Unit Case Surface Area (㎡)
0.260
Weight per Unit Case (kg/unit)
5.0
Weight per Square Meter (kg/㎡)
19.8
Physical Pixel Density (pixels/㎡)
250,000
Flatness of Unit Case (mm)
±0.2
Unit Case material
Die casting alluminum
Service access
Front or Rear
Min. Brightness (After Calibration)
300 ~ 1,000
Color Temperature
3,200 - 9,300
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
140
Brightness Uniformity
≥97%
Color Uniformity
±0.015Cx,Cy
Contrast Ratio
6,000
Processing Depth (bit)
16
Power Consumption (W/Unit, Avg.)
170
Power Consumption (W/Unit, Max.)
330
Power Consumption (W/㎡, Max.)
1270(@1,000nit)
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
3,840
Lifetime (Half brightness)* br* The Lifetime(Half brightness) spec is subject to LED package spec.
100,000
Operating Temperature(℃)
0∘to +40∘
Operating Humidity
10-80%RH(TBD)
IP rating Front
-
IP rating Rear
-
Controller
LCLG003
