LG Curved OLED 55" Signage - 55EF5K-L
A woman and a child are going up a tunnel made of flexible Curved Open Frame OLED Signage through an escalator.
* All images in this web page are for illustrative purposes only.
Blending in with the space while captivating everyone’s mind. LG OLED signage offers flexible design. Beyond its informative features, LG OLED signage delivers unsurpassed advertising effectiveness, redesigning space as a prestige-enhancing landmark with perfect colours and innovative forms.
The woman is looking at the weather and time information displayed on the curved screen.
Several screens can be arranged like tiles to embody the desired size.
A screen of LG OLED Signage is slim, light, and flexible.
Children are looking at the screen that curved in a wave-shaped interestingly in which the universe is expressed.
The EF5K series is designed to bend the screen convex or concave, allowing flexibility in adjusting even when sudden requests are received on-site.
* A Curvature Calibrator needs to be purchased separately. Please contact your regional LG sales representatives for details.
Screen Size (Inch)
55"
Panel Technology
OLED
Back Light Type
OLED
Aspect Ratio
16:9
Native Resolution
1920x1080 (FHD)
Refresh Rate
120Hz
Brightness
150/400nit (APL 100%/25%)
Contrast Ratio
150,000 : 1
Color Gamut
BT709 120%
Viewing Angle (H x V)
178x178
Color Depth (Number of Colors)
10bit(R), 1.07Bilion colours
Response Time
1ms (G to G), 8ms (MPRT)
Surface Treatment (Haze)
Hard coating (2H) Reflectance Typ. 1.2%
Life time
30,000 Hrs (Typ.)
Operation Hours (Hours/Day)
18/7 (Moving Content Only)
Portait / Landscape
Yes
HDMI In
Yes(1), HDCP1.4
DP In
Yes(1), HDCP1.3
RS232C In
Yes(1)
RJ45(LAN) In
Yes(1)
IR In
Yes(1), External IR Receiver
USB In
USB2.0 Type A(2)
DP Out
Yes(1)
Audio Out
Yes(1)
RS232C Out
Yes(1) (w/ IR Out)
RJ45(LAN) Out
Yes(1)
Bezel Color
Black
Bezel Width
T/R/L/B : 0.6/6.7/6.7/0.6mm (LandScape, Off Bezel)
T/R/L/B : 0.6/6.7/6.7/0.6mm (Portrait, Off Bezel)
T/R/L/B : 5.0/7.6/7.6/10.6mm (LandScape, On Bezel)
T/R/L/B : 5.0/13.2/7.8/5.0mm (Portrait, On Bezel)
Weight (Head)
5.8Kg (LandScape, Head)
7.0Kg (Portrait, Head)
3.5Kg (Signage Box)
Packed Weight
17.0Kg (LandScape)
17.6Kg (Portrait)
Monitor Dimensions (W x H x D)
1224.9 x 696.2 x 38.0mm (LandScape, Head, w/Pemnut)
701.4 x 1219.7 x 38.0mm (Portrait, Head, w/Pemnut)
1224.9 x 696.2 x 12.4mm (Landscape, Head, w/o Pemnut)
701.4 x 1219.7 x 12.4mm (Landscape, Head, w/o Pemnut)
413 x 353 x 57.3mm (Signage Box)
Carton Dimensions (W x H x D)
1360 x 842 x 252mm
Internal Memory (eMMC)
16GB
Temperature Sensor
Yes
FAN (Built-in)
Yes
OS Ver. (webOS)
webOS4.0
Local Contents Scheduling
Yes
Group Manager
Yes
USB Plug & Play
Yes
Fail over
Yes
RS232C Sync
Yes
Local Network Sync
Yes
Video Tag
Yes (4)
Screen Rotation
Yes
External Input Rotation
Yes
Gapless Playback
Yes
Tile Mode Setting
Yes
Setting Data Cloning
Yes
SNMP
Yes
ISM Method
Yes
Auto Set ID
Yes
Status Mailing
Yes
Control Manager
Yes
Crestron Connected
Yes
PM mode
Yes
Wake on LAN
Yes
HDMI-CEC
Yes
SI Server Setting
Yes
Pro:Idiom
Yes
Scan Inversion
Yes
The security update is supported for
5 years from the product launch date stated at https://lgsecurity.lge.com/bulletins/idproducts
Operation Temperature
0 °C to 40 °C
Operation Humidity
10 % to 80 %
Power Supply
AC 100-240V~, 50/60Hz
Power Type
Built-In Power
Typ.
309W
Max.
318W
BTU (British Thermal Unit)
1054 BTU/Hr(Typ.), 1085 BTU/Hr(Max)
DPM
0.5W
Power off
0.5W
Safety
IEC 60950-1 / EN 60950-1 / UL 60950-1
EMC
FCC Class "A" / CE / KC
ERP / Energy Star
Yes / No
SuperSign CMS
Yes (v3.0)
SuperSign Control+
Yes (v1.7 / v1.9)
SuperSign WB
Yes (v3.7.15)
OSD
English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Arabic
Basic
Remote Controller(include battery 2ea), Power Cord, QSG, IR receiver, Regulation Book, Phone to RS232C Gender, FFC Cables(220mmx4ea for connection between panel and Sinage box), DP Cable(2M), LAN Cable(1.5M), RS232 Cable(4P-4P,1.5M), LC Cable(VLC,3M), Tape(4EA for Cabling), Screw(M3xL4.5,30EA / M3xL5.5,50EA / M3x3.5, 10EA), Shield Cover Assy', Tiling Set Fixer 6EA, Flex Bar 2EA
Tilt (Face down)
Yes
