*Mounting accessories (wall mount, stand, etc.) are not included with LG products.
*Network-based control
*The availability of the "Signage365Care" service differs by region, so please contact the LG sales representative in your region for more details.
Pitch Name
P1.5
Pixel Configuration
3 in 1 SMD
Pixel Pitch (mm)
1.50
Screen Resolution (WxH)
1,920x1,080
Screen Dimension (W x H x D,mm)
2,880 x 1,620 x 128.5 (w/o Screen Frame)
Screen Weight (kg)
175 (w/o Screen Frame)
No. of Modules per Unit Case (W x H)
4x3
Unit Case Resolution (W x H)
640x360
Unit Case Dimensions (W x H x D, mm)
960x540x128.5
Unit Case Surface Area (㎡)
0.518
Weight per Unit Case (kg/unit)
Master: 20.85
Slave: 19.24
Weight per Square Meter (kg/㎡)
37.6
Physical Pixel Density (pixels/㎡)
444,444
Flatness of Unit Case (mm)
±0.2
Unit Case material
Front : Die Casting Aluminum
Rear : PC+ABS
Service access
Front and Rear
Max. Brightness (cd/m²)
500
Color Temperature
6,500
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
140
Brightness Uniformity
95%
Color Uniformity
±0.015Cx,Cy
Contrast Ratio
5,000
Processing Depth (bit)
16(HDR10, HDR10 Pro)
Power Consumption (W/Screen, Max.)
2,900
Power Consumption (W/Screen, Avg.)
980
Power Consumption (W/m², Max.)
622
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
3,840
Sound Output (Max.)
162W
Lifetime (Half Brightness, hrs)
100,000 (It is subject to LED package spec.)
Operating Temperature (°C)
0°C to 40°C
Operating Humidity
10-80% RH
Safety
IEC 60950-1 / EN 60950-1 / UL 60950-1
EMC
FCC Class A / CE / KC
Environment
RoHS
Video Inputs
HDMI In(3), DP In, USB
Control
RJ45 In, RS232C In/out
Special Features
Temperature Sensor, IR & Ambient Light Sensor, Audio Out, Crestron Connected(Network based control)
Basic Accessory
Data Cable, LAN Cable, Power Cord, RS232C Gender (9pin to Phone Jack), Remote Controller, IR Receiver, Manual
