P1.56" LED All-in-one | Indoor LED Signage
LAPA136-GF
Orders for the Scottish Islands and remote areas will be delivered by 3PL. The 3PL will contact you to arrange a suitable delivery date.
Delivery fees vary by postcode and may include additional charges for Highland or remote areas. Final shipping costs will be confirmed at checkout.
Further information regarding delivery can be found in our Delivery Terms and Conditions.
Are you sure you want to remove the coupon?
Pixel Configuration
Single SMD
Pixel Pitch (mm)
1.56
Module Resolution (WxH)
192*108
Module Dimensions(WxH,mm)
300*168.75
Physical Pixel Density (pixels/㎡)
409,600
Flatness of Cabinet (mm)
±0.15
Cabinet material
Aluminum
Service access
Front
Screen Resolution (WxH)
1,920x1,080
No. of Modules per Screen (WxH)
10x10 (Total 100)
Screen Dimensions (W x H x D, mm, including bezel)
3,005 X 1,692.5 X 29.95 (Thickest 59.5)
Screen Surface Area (㎡)
5.06
Weight of the screen
108.5
Visual Viewing Angle (Horizontal)
150
Visual Viewing Angle (Vertical)
150
Brightness Uniformity(%)
98%
Color Uniformity
±0.015Cx,Cy
Contrast Ratio
3,000:1
Processing Depth (bit)
16 (HDR10, HDR10 Pro)
Color Temperature
3,200~9,300
Power Consumption (W/㎡, Max.)
260
Heat Dissipation (BTU/h/㎡, Max.)
888
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
3,840
Power Consumption (W/Screen, Max.)
1,300
Power Consumption (W/Screen, Avg.)
650
Heat Dissipation (BTU/h/Screen, Max.)
4,436
Heat Dissipation (BTU/h/Screen, Avg.)
2,218
LED Lifetime (Half brightness)
100,000
Operating Temperature(℃)
0℃ to +40℃
Operating Humidity
10~90%RH
IP rating Front
IP30
IP rating Rear
IP30
Certification
CE,FCC,ETL,CB,CE-RED
EMC Class A
Environment
RoHS, REACH
Controller
Embedded(webOS)
Speaker
Built-in(9W+9W)
I/O Port
HDMI(3), DP(1), USB, LAN, RS232C In/Out, IR, Digital Audio Out (1, SPDIF Optical)
