Ultra Slim Series
LSCB025-RK
Orders for the Scottish Islands and remote areas will be delivered by 3PL. The 3PL will contact you to arrange a suitable delivery date.
Delivery fees vary by postcode and may include additional charges for Highland or remote areas. Final shipping costs will be confirmed at checkout.
Further information regarding delivery can be found in our Delivery Terms and Conditions.
Are you sure you want to remove the coupon?
Power Consumption (W/㎡, Max.)
493.83
Refresh Rate (Hz)
3,840
Frame Rate (Hz)
50 / 60
Heat Dissipation (BTU/h/Cabinet, Avg.)
116.01
Heat Dissipation (BTU/h/Cabinet, Max.)
341.21
Heat Dissipation (BTU/h/㎡, Max.)
1,685.01
Power Consumption (W/Cabinet, Avg.)
34
Power Consumption (W/Cabinet, Max.)
100
Power Supply (V)
100 to 240
LED Lifetime (Half brightness)
100,000
Operating Humidity
0~80%RHv
Operating Temperature(℃)
-10℃ to +45℃
IP rating Rear
IP30
IP rating Front
IP30
Brightness Uniformity(%)
0.97
Visual Viewing Angle (Horizontal)
160
Max Brightness (After Calibration, nit)
800
Color Temperature (K)
3,200~9,300
Color Uniformity
±0.003Cx,Cy
Contrast Ratio
5,000:1
Processing Depth (bit)
14 (HDR10, HDR10 Pro)
Visual Viewing Angle (Vertical)
160
Cabinet material
Die-casting Aluminum
Pixel Configuration
Single SMD
Cabinet Dimensions (W x H x D, mm)
600x337.5x34
Cabinet Resolution (WxH)
240x135
Cabinet Surface Area (㎡)
0.2
Flatness of Cabinet (mm)
±0.1
Module Dimensions(WxH,mm)
300x337.5
Module Resolution (WxH)
120x135
No. of Modules per Cabinet (WxH)
2x1
Physical Pixel Density (pixels/㎡)
160,000
Pixel Pitch (mm)
2.5
Service access
Front
Weight per Cabinet (kg/unit)
5.3
Weight per Module (kg)
0.64
Weight per Square Meter (kg/㎡)
26.17
90 degree corner cut
O
Controller
CVCA
Environment
RoHS, REACH
Model name
LSCB025-RK
Certification
CE, FCC, ETL, EMC Class-B, Fire Protection
