Screen Size
55"
Resolution
1,920 x 1,080 (FHD)
Brightness (APL25%, Typ., cd/m²)
400
Input
HDMI, DP, USB
Output
DP, Audio
External Control
RS232C in/out, IR out, RJ45 in/out, IR receiver
Bezel Width
(Off-bezel) 1.2/1.2/1.2/1.2 mm (U/B/L/R)
(On-bezel) 5.6/5.6/5.6/11.0 mm (U/B/L/R)
(Seam) 3.5mm
Dimension (W x H x D)
(Head)
1×2: 1,382 x 1,220.9 x 7.9 mm
1×3: 2,066.3 x 1,220.9 x 7.9 mm
(T-Con Box) 312.2 x 213.4 x 16 mm
(Signage Box) 412.6 x 222.4 x 64.3 mm
Weight
(Head)
1x2: 18.4kg, 1x3: 27.4kg
(T-Con Box) 1.6kg/ea
(Signage Box) 4.3kg/ea
Packaged Weight (Set)
1x2: 78.2kg, 1x3: 93.7kg
Operation Temperature
0°C to 40°C
Operation Humidity
10% to 80%
Power Supply
100-240 V~, 50/60 Hz
Power Type
Built-In Power
Safety
UL/cUL/CB/TUV/KC
EMC
FCC Class "A"/CE/KC
ErP / Energy Star
Yes/NA
OPS type compatible
Yes
External Media player Attatchable
Yes
Content Management Software
SuperSign CMS
Control and Monitoring Software
SuperSign Link
Basic
Remote Controller (2 Batteries Included), Power Cord, QSG, HDMI Cable (3M x 1ea for Connection between T-Con Box and Signage Box), Power Hanness Cable (3M x 1ea for Connection between T-Con Box and Signage Box), IR Receiver, Regulation Book, Phone to RS232C Gender, Signage Box Jack Cover, T-Con Box Jack Cover, Signage Box Mounting Bracket, T-Con Box Mounting Bracket, FFC Cables (350mm x 4ea, 1600mm x 4ea for Connection between Panel and T-Con Box), Phone
Optional
OPS Kit (KT-OPSA)
